IGBT Modules
Review IGBT Modules IGBTs components in this filtered selection. Compare manufacturer information, availability, pricing, datasheets and key specifications to narrow down suitable parts for your application.
If the exact part or specification you need is not listed, send the manufacturer part number, target parameters and quantity to JIEXIN Electronics for sourcing and quotation support.
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | IGBT Type | Configuration | Voltage - Collector Emitter Breakdown (Max) | Current - Collector (Ic) (Max) | Power - Max | Vce(on) (Max) @ Vge, Ic | Current - Collector Cutoff (Max) | Input Capacitance (Cies) @ Vce | Input | NTC Thermistor | Operating Temperature | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
FP15R06W1E3BOMA1IGBT MODULE 600V 22A 81W |
12 |
|
Datasheet | EasyPIM™ | Module | Tray | Active | Trench Field Stop | Three Phase Inverter | 600 V | 22 A | 81 W | 2V @ 15V, 15A | 1 mA | 830 pF @ 25 V | Standard | Yes | -40°C ~ 150°C | Chassis Mount | Module |
|
|
FP15R12W1T7B3BOMA1IGBT MODULE LOW POWER EASY |
1 |
|
Datasheet | TrenchStop™ | Module | Bulk | Active | Trench Field Stop | Half Bridge Inverter | 1200 V | - | - | - | - | - | Standard | No | 175°C (TJ) | Chassis Mount | AG-EASY1B-2 |
.jpg "FS25R12W1T7BOMA1")
|
FS25R12W1T7BOMA1LOW POWER EASY AG-EASY1B-1 |
19 |
|
Datasheet | EasyPACK™ | Module | Tray | Active | Trench Field Stop | Three Phase Inverter | 1200 V | 25 A | - | - | 5.6 µA | 4.77 nF @ 25 V | Standard | Yes | -40°C ~ 175°C (TJ) | Chassis Mount | AG-EASY1B |
|
|
FP10R12W1T4B3BOMA1IGBT MOD 1200V 20A 105W |
22 |
|
Datasheet | EasyPIM™ | Module | Bulk | Active | Trench Field Stop | Three Phase Inverter | 1200 V | 20 A | 105 W | 2.25V @ 15V, 10A | 1 mA | 600 pF @ 25 V | Standard | Yes | -40°C ~ 150°C | Chassis Mount | Module |
|
|
FS25R12W1T4B11BOMA1IGBT MOD 1200V 45A 205W |
17 |
|
Datasheet | EasyPACK™ | Module | Tray | Active | Trench Field Stop | Three Phase Inverter | 1200 V | 45 A | 205 W | 2.25V @ 15V, 25A | 1 mA | 1.45 nF @ 25 V | Standard | Yes | -40°C ~ 150°C | Chassis Mount | Module |
|
|
FP30R06W1E3BOMA1IGBT MODULE 600V 37A 115W |
11 |
|
Datasheet | EasyPIM™ | Module | Tray | Active | Trench Field Stop | Three Phase Inverter | 600 V | 37 A | 115 W | 2V @ 15V, 30A | 1 mA | 1.65 nF @ 25 V | Standard | Yes | -40°C ~ 150°C | Chassis Mount | Module |
|
|
FP15R12W1T7B11BOMA1IGBT MODULE LOW POWER EASY |
7,025 |
|
Datasheet | TrenchStop™ | Module | Bulk | Active | Trench Field Stop | Half Bridge Inverter | 1200 V | - | - | - | - | - | Standard | No | 175°C (TJ) | Chassis Mount | AG-EASY1B-2 |
|
DDB6U50N16W1RPBPSA1LOW POWER EASY AG-EASY1B-711 |
27 |
|
Datasheet | - | Module | Tray | Active | Trench Field Stop | Single Chopper | 1200 V | 50 A | - | 1.5V @ 15V, 50A | 6.2 µA | 11.1 nF @ 25 V | Three Phase Bridge Rectifier | No | -40°C ~ 175°C (TJ) | Chassis Mount | AG-EASY1B |
|
|
DDB6U50N16W1RPB11BPSA1LOW POWER EASY |
30 |
|
Datasheet | - | Module | Tray | Active | Trench Field Stop | Single Chopper | 1200 V | 50 A | - | 1.5V @ 15V, 50A | 6.2 µA | 11.1 nF @ 25 V | Three Phase Bridge Rectifier | No | -40°C ~ 175°C (TJ) | Chassis Mount | AG-EASY1B |
|
FS25R12W1T7PB11BPSA1LOW POWER EASY AG-EASY1B-2 |
9 |
|
Datasheet | EasyPACK™, TRENCHSTOP™ | Module | Tray | Active | Trench Field Stop | Three Phase Inverter | 1200 V | 25 A | - | - | 5.6 µA | 4.77 nF @ 25 V | Standard | Yes | -40°C ~ 175°C (TJ) | Chassis Mount | Module |
