Wireless Charging Coils

Explore Wireless Charging Coils parts from multiple manufacturers, with model information, availability, datasheets and technical specifications for engineering and purchasing.

For parts that are not shown in the list, send the manufacturer part number, quantity or BOM to JIEXIN Electronics. Our team can assist with availability checks and quotation support.

Mfr. Part #	Availability	Price	Quantity	Datasheet	Series	Packaging	Product Status	Function	Type	Inductance	Tolerance	DC Resistance (DCR)	Q @ Freq	Current Rating (Amps)	Current - Saturation (Isat)	Frequency - Self Resonant	Operating Temperature	Size / Dimension
760308201 RX 1 COIL 1 LAYER 10UH 4.5A Würth Elektronik	3,284	9.15	RFQ	Datasheet	WE-WPCC	Tray	Active	Receiver	1 Coil, 1 Layer	10µH	±5%	200mOhm Max	50 @ 125kHz	3.5A	8A	15MHz	-20°C ~ 105°C	1.46" L x 1.46" W x 0.07" H (37.0mm x 37.0mm x 1.8mm)
AWCCA-TX1005545-F002 WIRELESS CHARGING COIL Abracon LLC	2,121	6.83	RFQ	Datasheet	AWCCA	Tray	Not For New Designs	Transmitter	3 Coil, 1 Layer	12.5µH, 11.5µH, 12.5µH	±10%	75mOhm	90 @ 100kHz	-	-	-	-25°C ~ 85°C	3.94" L x 2.17" W x 0.18" H (100.0mm x 55.0mm x 4.5mm)
1461794011 RX TX 2 COIL 1 LAYER 9.6UH 5.6UH Molex	3,754	10.46	RFQ	Datasheet	NuCurrent, PowerLife, 146179	Tray	Active	Receiver, Transmitter	2 Coil, 1 Layer	9.6µH, 5.6µH	±2%	550mOhm, 38mOhm	18 @ 200kHz, 160 @ 200kHz	-	-	-	-	1.06" Dia x 0.15" H (27.0mm x 3.7mm)
1461798021 RX 1 COIL 1 LAYER 4UH Molex	3,408	10.50	RFQ	Datasheet	NuCurrent, PowerLife, 146179	Bulk	Obsolete	Receiver	1 Coil, 1 Layer	4µH	±2%	235mOhm	115 @ 6.78MHz	-	-	-	-	1.38" Dia x 0.02" H (35.0mm x 0.6mm)
1461794001 RX 2 COIL, 1 LYR 8.9UH Molex	4,776	11.22	RFQ	Datasheet	NuCurrent, PowerLife, 146179	Bulk	Obsolete	Receiver	2 Coil, 1 Layer	8.9µH	±2%	350mOhm	25 @ 200kHz	-	-	-	-	2.58" L x 1.91" W x 0.02" H (65.5mm x 48.4mm x 0.5mm)
1461798001 RX 1 COIL 1 LAYER 2.9UH Molex	4,660	11.22	RFQ	Datasheet	NuCurrent, PowerLife, 146179	Bulk	Obsolete	Receiver	1 Coil, 1 Layer	2.9µH	±2%	120mOhm	160 @ 6.78MHz	-	-	-	-	2.24" L x 2.86" W x 0.04" H (56.8mm x 72.8mm x 1.0mm)
RWC5353EJ240-500 TX 1 COIL 2 LAYER 24UH 5.5A Laird-Signal Integrity Products	3,971	10.15	RFQ	Datasheet	RWC	Box	Active	Transmitter	1 Coil, 2 Layer	24µH	±10%	75mOhm Max	90 @ 100kHz	5.5A	10A	-	-40°C ~ 125°C	2.09" L x 2.09" W x 0.26" H (53.0mm x 53.0mm x 6.7mm)
1461790001 RX 1 COIL 1 LAYER 17.3UH Molex	4,874	11.14	RFQ	Datasheet	NuCurrent, PowerLife, 146179	Bulk	Obsolete	Receiver	1 Coil, 1 Layer	17.3µH	±2%	450mOhm	-	-	-	-	-	1.69" L x 1.97" W x 0.02" H (43.0mm x 50.0mm x 0.5mm)
CTTX505035BF-6R3K WIRELESS TRANSMITTER COIL Central Technologies	3,665	4.65	RFQ	Datasheet	CTTX505035BF	Bulk	Active	Transmitter	1 Coil, 2 Layer, Bifilar	6.3µH	±10%	25mOhm	-	10A	-	-	-40°C ~ 85°C	1.97" L x 1.97" W x 0.16" H (50.0mm x 50.0mm x 4.0mm)
1461792001 RX 2 COIL 1 LAYER 10.6UH Molex	3,458	11.17	RFQ	Datasheet	NuCurrent, PowerLife, 146179	Bulk	Obsolete	Receiver	2 Coil, 1 Layer	10.6µH	±2%	190mOhm	24 @ 200kHz	-	-	-	-	2.55" L x 2.11" W x 0.06" H (64.7mm x 53.6mm x 1.4mm)
WT1005690-11F2-M9-G TX COIL UNIT TDK Corporation	1,668	11.26	RFQ	Datasheet	WT	Box	Active	-	-	-	-	-	-	-	-	-	-	-
STX106530612R5KT 3 COIL 1 LAYER 12.5UH, 11.5UH, 1 Superworld Electronics (S) Pte. Ltd.	4,947	0.00	RFQ	Datasheet	STX	Bulk	Active	Transmitter	3 Coil, 1 Layer	12.5µH, 11.5µH, 12.5µH	±10%	80mOhm Max	-	6.5A	-	-	-40°C ~ 85°C	4.17" L x 2.09" W x 0.24" H (106.0mm x 53.0mm x 6.0mm)
WRM483245-15F5-5V-G RX 1 COIL 1 LYR 13UH TDK Corporation	4,966	0.00	RFQ	Datasheet	WRM	Tray	Obsolete	Receiver	1 Coil, 1 Layer	13µH	-	270mOhm	-	-	-	-	-	2.99" L x 1.26" W x 0.04" H (76.0mm x 32.0mm x 1.0mm)
WT-1005660-12K2-A6-G TX 3 COIL 1 LYR 12.5UH/11.5UH TDK Corporation	2,826	15.96	RFQ	Datasheet	WT	Tray	Not For New Designs	Transmitter	3 Coil, 1 Layer	12.5µH, 11.5µH, 12.5µH	±10%	80mOhm Max	70 @ 100kHz	-	-	-	-30°C ~ 70°C	3.94" L x 2.20" W x 0.11" H (100.0mm x 56.0mm x 2.8mm)
760308102144 WE-WPCC WIRELESS POWER CHARGING Würth Elektronik	2,235	22.73	RFQ	Datasheet	WE-WPCC	Box	Obsolete	Transmitter	1 Coil, 2 Layer	19.5µH	±10%	45mOhm Max	220 @ 125kHz	9.5A	20A	5MHz	-20°C ~ 105°C	2.10" L x 2.10" W x 0.28" H (53.30mm x 53.30mm x 7.00mm)
QPT-6071A TRANSMITTER QST	3,939	0.00	RFQ	Datasheet	-	Bulk	Active	Transmitter	1 Coil, 1 Layer	6.5µH	±10%	380mOhm Max	65 @ 100kHz	-	-	-	0°C ~ 40°C	1.97" Dia x 0.09" H (50.0mm x 2.3mm)
2114 UNIVERSAL QI WIRELESS CHARGING M Adafruit Industries LLC	1,696	24.95	RFQ	Datasheet	-	Bulk	Active	Receiver	-	-	-	-	-	600mA	-	-	-	-
2115 UNIVERSAL QI WIRELESS CHARGING M Adafruit Industries LLC	4,777	0.00	RFQ	Datasheet	-	Bulk	Obsolete	Receiver	-	-	-	-	-	600mA	-	-	-	-
2116 UNIVERSAL QI WIRELESS CHARGING M Adafruit Industries LLC	1,797	0.00	RFQ	Datasheet	-	Bulk	Obsolete	Receiver	-	-	-	-	-	600mA	-	-	-	-
2117 UNIVERSAL QI WIRELESS CHARGING M Adafruit Industries LLC	1,655	0.00	RFQ	Datasheet	-	Bulk	Obsolete	Receiver	-	-	-	-	-	600mA	-	-	-	-

FAQ

Frequently Asked Questions

What are Wireless Charging Coils components used for?

Wireless Charging Coils components are used in a wide range of electronic equipment and systems. Their exact function depends on the device, circuit design and technical requirements of the application.

How do I choose the right Wireless Charging Coils part?

Compare the manufacturer part number, key specifications, package type, operating conditions, availability and datasheet information. For replacement projects, always verify the critical electrical and mechanical parameters before selecting an alternative.

Can JIEXIN Electronics help source obsolete or hard-to-find Wireless Charging Coils parts?

Yes. Send us the required manufacturer part number, quantity or BOM. Our sourcing team can help check stock availability, lead time, alternative sourcing options and quotation details.

How can I request pricing and availability?

Submit the part number, manufacturer and required quantity through our RFQ form. JIEXIN Electronics will review your request and provide available stock, pricing and sourcing information.
