TVS Diodes
Explore TVS Diodes parts from multiple manufacturers, with model information, availability, datasheets and technical specifications for engineering and purchasing.
For parts that are not shown in the list, send the manufacturer part number, quantity or BOM to JIEXIN Electronics. Our team can assist with availability checks and quotation support.
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Type | Unidirectional Channels | Bidirectional Channels | Voltage - Reverse Standoff (Typ) | Voltage - Breakdown (Min) | Voltage - Clamping (Max) @ Ipp | Current - Peak Pulse (10/1000µs) | Power - Peak Pulse | Power Line Protection | Applications | Capacitance @ Frequency | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SMBJ48CATVS DIODE 48VWM 77.4VC |
200 |
|
Datasheet | DO-214AA (SMB) | SMBJ | Strip | Active | Zener | - | 1 | 48V | 53.3V | 77.4V | 7.75A | 600W | - | General Purpose | - | -55°C ~ 150°C | - | - | Surface Mount | - |
|
1.5KE200ABULKTVS DIODE 171VWM 274VC DO201 |
500 |
|
Datasheet | DO-201AA, DO-27, Axial | 1.5KE | Bag | Active | Zener | 1 | - | 171V | 190V | 274V | 5.5A | 1500W (1.5kW) | No | General Purpose | - | -65°C ~ 175°C (TJ) | - | - | Through Hole | DO-201 |
|
SMBJ24CATVS DIODE 24VWM 38.9VC |
500 |
|
Datasheet | DO-214AA (SMB) | SMBJ | Strip | Active | Zener | - | 1 | 24V | 26.7V | 38.9V | 15.42A | 600W | - | General Purpose | - | -55°C ~ 150°C | - | - | Surface Mount | - |
|
SMCJ220CATVS DIODE 220VWM 356VC |
200 |
|
Datasheet | DO-214AB (SMC) | SMCJ | Strip | Active | Zener | - | 1 | 220V | 246V | 356V | 4.2A | 1500W (1.5kW) | - | General Purpose | - | -55°C ~ 150°C | - | - | Surface Mount | - |
|
|
1.5KE30CBULKTVS DIODE 24.3VWM 43.5VC DO201 |
1,000 |
|
Datasheet | DO-201AA, DO-27, Axial | 1.5KE6.8C | Bag | Active | Zener | - | 1 | 24.3V | 27V | 43.5V | 34.5A | 1500W (1.5kW) | No | General Purpose | - | -65°C ~ 175°C (TJ) | - | - | Through Hole | DO-201 |
|
SMCJ26ATVS DIODE 26VWM 42.1VC |
200 |
|
Datasheet | DO-214AB (SMC) | SMCJ | Strip | Active | Zener | 1 | - | 26V | 28.9V | 42.1V | 35.63A | 1500W (1.5kW) | - | General Purpose | - | -55°C ~ 150°C | - | - | Surface Mount | - |
|
|
1.5KE130CABULTVS DIODE 111VWM 179VC DO201 |
1,000 |
|
Datasheet | DO-201AA, DO-27, Axial | 1.5KE6.8C | Bag | Active | Zener | - | 1 | 111V | 124V | 179V | 8.4A | 1500W (1.5kW) | No | General Purpose | - | -65°C ~ 175°C (TJ) | - | - | Through Hole | DO-201 |
|
|
1.5KE33CABULKTVS DIODE 28.2VWM 45.7VC DO201 |
500 |
|
Datasheet | DO-201AA, DO-27, Axial | 1.5KE6.8C | Bag | Active | Zener | - | 1 | 28.2V | 31.4V | 45.7V | 33A | 1500W (1.5kW) | No | General Purpose | - | -65°C ~ 175°C (TJ) | - | - | Through Hole | DO-201 |
|
3.0SMCJ36CASurface Mount Uni/Bi-Directional |
150 |
|
Datasheet | DO-214AB, SMC | 3.0SMCJ-AT | Tape & Reel (TR) | Active | Zener | - | 1 | 36V | 40V | 58.1V | 51.6A | 3000W (3kW) | No | Telecom | - | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SMC (DO-214AB) |
|
3.0SMCJ5P0ASurface Mount Uni/Bi-Directional |
100 |
|
Datasheet | - | - | Tape & Reel (TR) | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
3.0SMCJ170ASurface Mount Uni/Bi-Directional |
100 |
|
Datasheet | DO-214AB, SMC | 3.0SMCJ-AT | Tape & Reel (TR) | Active | Zener | 1 | - | 170V | 189V | 275V | 10.9A | 3000W (3kW) | No | Telecom | - | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SMC (DO-214AB) |
|
5.0SMCJ170ASurface Mount Uni/Bi-Directional |
100 |
|
Datasheet | DO-214AB, SMC | 5.0SMCJ-AT | Tape & Reel (TR) | Active | Zener | 1 | - | 170V | 189V | 275V | 18.2A | 5000W (5kW) | No | Telecom | - | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SMC (DO-214AB) |
|
|
5.0SMCJ5P0ASurface Mount Uni/Bi-Directional |
100 |
|
Datasheet | DO-214AB, SMC | 5.0SMCJ-AT | Tape & Reel (TR) | Active | Zener | 1 | - | 5V | 6.4V | 9.2V | 543.6A | 5000W (5kW) | No | Telecom | - | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SMC (DO-214AB) |
|
SM8S24CATVS 6600W DIODE 24VWM Bi-Dir DO- |
100 |
|
Datasheet | DO-218AB | - | Tape & Reel (TR) | Active | Zener | - | 1 | 24V | 26.7V | 38.9V | 170A | 6600W (6.6kW) | No | - | - | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | DO-218AB |
|
|
SM8S26ATVS 6600W DIODE 26VWM Uni-Dir DO |
100 |
|
Datasheet | DO-218AB | - | Tape & Reel (TR) | Active | Zener | 1 | - | 26V | 28.9V | 42.1V | 157A | 6600W (6.6kW) | No | - | - | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | DO-218AB |
|
|
SM8S20CATVS 6600W DIODE 20VWM Bi-Dir DO- |
100 |
|
Datasheet | DO-218AB | - | Tape & Reel (TR) | Active | Zener | - | 1 | 20V | 22.2V | 32.4V | 204A | 6600W (6.6kW) | No | - | - | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | DO-218AB |
|
|
SM8S58ATVS 6600W DIODE 58VWM Uni-Dir DO |
100 |
|
Datasheet | DO-218AB | - | Tape & Reel (TR) | Active | Zener | 1 | - | 58V | 64.4V | 93.6V | 64.1A | 6600W (6.6kW) | No | - | - | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | DO-218AB |
|
30KP36AUni-polar TVS 30000W, Case Type: |
100 |
|
Datasheet | D-6, Axial | 30KP | Bulk | Active | Zener | 1 | - | 36V | 40V | 61.8V | 502A | 30000W (30kW) | No | General Purpose | - | -55°C ~ 175°C (TJ) | - | - | Through Hole | D6 |
|
GG040205100N2PTVS DIODE 5VWM 12VC 0402 |
4,322 |
|
Datasheet | 0402 (1005 Metric) | GiGUARD | Tape & Reel (TR) | Active | Zener | - | 1 | 5V | 5.5V | 12V | 8A (8/20µs) | 96W | No | General Purpose | 10pF @ 1MHz | -55°C ~ 125°C | - | - | Surface Mount | 0402 (1005 Metric) |
|
LXES1UTAA1-157TVS DIODE 6VWM 2DFN |
6,371 |
|
Datasheet | 2-XDFN | LXESxxT | Tape & Reel (TR) | Active | Zener | - | 1 | 6V | 7V | - | - | - | No | General Purpose | 0.5pF @ 1MHz | -40°C ~ 85°C (TA) | - | - | Surface Mount | 2-DFN (1x0.6) |
Frequently Asked Questions
What are TVS Diodes components used for?
TVS Diodes components are used in a wide range of electronic equipment and systems. Their exact function depends on the device, circuit design and technical requirements of the application.
How do I choose the right TVS Diodes part?
Compare the manufacturer part number, key specifications, package type, operating conditions, availability and datasheet information. For replacement projects, always verify the critical electrical and mechanical parameters before selecting an alternative.
Can JIEXIN Electronics help source obsolete or hard-to-find TVS Diodes parts?
Yes. Send us the required manufacturer part number, quantity or BOM. Our sourcing team can help check stock availability, lead time, alternative sourcing options and quotation details.
How can I request pricing and availability?
Submit the part number, manufacturer and required quantity through our RFQ form. JIEXIN Electronics will review your request and provide available stock, pricing and sourcing information.
