Fixed Inductors
Explore Fixed Inductors parts from multiple manufacturers, with model information, availability, datasheets and technical specifications for engineering and purchasing.
For parts that are not shown in the list, send the manufacturer part number, quantity or BOM to JIEXIN Electronics. Our team can assist with availability checks and quotation support.
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
RDC60-471K-RC470uH +/-10% Radial Drum Core |
4,048 |
|
Datasheet | RDC60 | Radial, Vertical Cylinder | Box | Active | Drum Core | - | 470 µH | ±10% | 13.5 A | 12.5A | Unshielded | 61mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial | 2.000" Dia (50.80mm) | 1.500" (38.10mm) |
|
|
RDC60-681K-RC680uH +/-10% Radial Drum Core |
1,478 |
|
Datasheet | RDC60 | Radial, Vertical Cylinder | Box | Active | Drum Core | - | 680 µH | ±10% | 11.4 A | 10.3A | Unshielded | 94mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial | 2.000" Dia (50.80mm) | 1.500" (38.10mm) |
|
RDC20-330K-RC33uH +/-10% Radial Drum Core |
2,246 |
|
Datasheet | RDC20 | Radial, Vertical Cylinder | Box | Active | Drum Core | - | 33 µH | ±10% | 5.5 A | 18.6A | Unshielded | 29mOhm Max | - | - | - | -40°C ~ 85°C | 1 kHz | - | Through Hole | Radial, Vertical Cylinder | 0.825" Dia (20.96mm) | 0.840" (21.34mm) |
|
|
RDC20-222K-RC2200uH +/-10% Radial Drum Core |
1,798 |
|
Datasheet | RDC20 | Radial, Vertical Cylinder | Box | Active | Drum Core | - | 2.2 mH | ±10% | 800 mA | 2A | Unshielded | 1.54Ohm Max | - | - | - | -40°C ~ 85°C | 1 kHz | - | Through Hole | Radial, Vertical Cylinder | 0.825" Dia (20.96mm) | 0.840" (21.34mm) |
|
|
RDC20-121K-RC120uH +/- 10% Radial Drum Core |
1,251 |
|
Datasheet | RDC20 | Radial, Vertical Cylinder | Box | Active | Drum Core | - | 120 µH | ±10% | 4 A | 9.4A | Unshielded | 90mOhm Max | - | - | - | -40°C ~ 85°C | 1 kHz | - | Through Hole | Radial, Vertical Cylinder | 0.825" Dia (20.96mm) | 0.840" (21.34mm) |
|
RDC30-390K-RC39uH +/-10% Radial Drum Core |
3,862 |
|
Datasheet | RDC30 | Radial, Vertical Cylinder | Box | Active | Drum Core | - | 39 µH | ±10% | 11.4 A | 19.1A | Unshielded | 22mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial | 1.100" Dia (27.94mm) | 0.840" (21.34mm) |
|
|
RDC30-502K-RC5000uH +/-10% Radial Drum Core |
2,558 |
|
Datasheet | RDC30 | Radial, Vertical Cylinder | Box | Active | Drum Core | - | 5 mH | ±10% | - | - | Unshielded | - | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial | 1.100" Dia (27.94mm) | 0.840" (21.34mm) |
|
|
RDC30-4R7M-RC4.7uH +/-10% Radial Drum Core |
4,202 |
|
Datasheet | RDC30 | Radial, Vertical Cylinder | Box | Active | Drum Core | - | 4.7 µH | ±20% | 21 A | 54A | Unshielded | 3mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Radial | 1.100" Dia (27.94mm) | 0.840" (21.34mm) |
|
SMAC30-10G-RC43nH +/-2% SMD Air Core Induct. |
4,339 |
|
Datasheet | SMAC30 | Nonstandard | Tape & Reel (TR) | Active | - | Air | 43 nH | ±2% | 4 A | - | Unshielded | 7.9mOhm Max | 106 @ 150MHz | 1.2GHz | - | -40°C ~ 125°C | 150 MHz | - | Surface Mount | - | 0.270" L x 0.120" W (6.86mm x 3.05mm) | 0.125" (3.18mm) |
|
SMAC25-47G-RC47nH +/-2% SMD Air Core Induct. |
4,090 |
|
Datasheet | - | Nonstandard | Tape & Reel (TR) | Active | Wirewound | Air | 47 nH | ±2% | 3 A | - | Unshielded | 5.6mOhm Max | 100 @ 150MHz | 2.1GHz | - | -40°C ~ 125°C | 150 MHz | - | Surface Mount | - | 0.190" L x 0.150" W (4.83mm x 3.81mm) | 0.165" (4.20mm) |
|
CC10-800NG-RC80nH +/-2% Ceramic Core Chip |
2,434 |
|
Datasheet | CC10 | 1008 (2520 Metric) | Tape & Reel (TR) | Active | Wirewound | Ceramic | 800 nH | ±2% | - | - | Unshielded | - | - | - | - | -40°C ~ 125°C | - | - | Surface Mount | 1008 | 0.115" L x 0.110" W (2.92mm x 2.79mm) | 0.087" (2.20mm) |
|
CC03-100NJ-RC100nH +/-5% Ceramic Core Chip |
2,901 |
|
Datasheet | CC03 | 0603 (1608 Metric) | Tape & Reel (TR) | Active | Wirewound | Ceramic | 100 nH | ±5% | - | 400mA | Unshielded | 780mOhm Max | 34 @ 150MHz | 1.4GHz | - | -40°C ~ 125°C | 150 MHz | - | Surface Mount | 0603 | 0.071" L x 0.047" W (1.80mm x 1.20mm) | 0.047" (1.20mm) |
|
|
CC03-220NJ-RC220nH +/-5% Ceramic Core Chip |
2,204 |
|
Datasheet | CC03 | 0603 (1608 Metric) | Tape & Reel (TR) | Active | Wirewound | Ceramic | 220 nH | ±5% | - | 200mA | Unshielded | 2.02Ohm Max | 25 @ 100MHz | 900MHz | - | -40°C ~ 125°C | 100 MHz | - | Surface Mount | 0603 | 0.071" L x 0.047" W (1.80mm x 1.20mm) | 0.047" (1.20mm) |
|
|
CC03-27NJ-RC27nH +/-5% Ceramic Core Chip |
1,315 |
|
Datasheet | CC03 | 0603 (1608 Metric) | Tape & Reel (TR) | Active | Wirewound | Ceramic | 27 nH | ±5% | - | 600mA | Unshielded | 140mOhm Max | 40 @ 250MHz | 2.8GHz | - | -40°C ~ 125°C | 250 MHz | - | Surface Mount | 0603 | 0.071" L x 0.047" W (1.80mm x 1.20mm) | 0.047" (1.20mm) |
|
PC1005-391K-RC390uH +/-10% Power Chip Inductor |
2,965 |
|
Datasheet | PC1005 | Nonstandard | Tape & Reel (TR) | Active | - | - | 390 µH | ±10% | 480 mA | - | Unshielded | 1.3Ohm Max | - | - | - | -40°C ~ 85°C | 1 kHz | - | Surface Mount | - | 0.394" L x 0.354" W (10.00mm x 9.00mm) | 0.228" (5.80mm) |
|
PC1006-531K-RC530uH +/-10% Power Chip Inductor |
1,882 |
|
Datasheet | PC1006 | Nonstandard | Tape & Reel (TR) | Active | - | - | 530 µH | ±10% | - | 620mA | Unshielded | 1.7Ohm Max | - | - | - | -40°C ~ 105°C | 1 kHz | - | Surface Mount | - | 0.394" L x 0.354" W (10.00mm x 9.00mm) | 0.272" (6.90mm) |
|
|
CC03-390NJ-RC390nH +/-5% Ceramic Core Chip |
3,514 |
|
Datasheet | CC03 | 0603 (1608 Metric) | Tape & Reel (TR) | Active | Wirewound | Ceramic | 390 nH | ±5% | - | 100mA | Unshielded | 3.6Ohm Max | 24 @ 100MHz | 700MHz | - | -40°C ~ 125°C | 100 MHz | - | Surface Mount | 0603 | 0.071" L x 0.047" W (1.80mm x 1.20mm) | 0.047" (1.20mm) |
|
|
CC03-3N9S-RC3.9nH +/-0.3nH Ceramic Core Chip |
2,926 |
|
Datasheet | CC03 | 0603 (1608 Metric) | Tape & Reel (TR) | Active | Wirewound | Ceramic | 3.9 nH | ±0.3nH | - | 700mA | Unshielded | 70mOhm Max | 22 @ 250MHz | 6.9GHz | - | -40°C ~ 125°C | 250 MHz | - | Surface Mount | 0603 | 0.071" L x 0.047" W (1.80mm x 1.20mm) | 0.047" (1.20mm) |
|
CC05-390NJ-RC390nH +/-5% Ceramic Core Chip |
3,088 |
|
Datasheet | - | 0805 (2012 Metric) | Tape & Reel (TR) | Active | Wirewound | Ceramic | 390 nH | ±5% | - | 290mA | Unshielded | 1.5Ohm Max | 48 @ 250MHz | 560MHz | - | -40°C ~ 125°C | 100 MHz | - | Surface Mount | 0805 | 0.090" L x 0.068" W (2.29mm x 1.73mm) | 0.060" (1.52mm) |
|
|
CC05-33NJ-RC33nH +/-5% Ceramic Core Chip |
1,660 |
|
Datasheet | - | 0805 (2012 Metric) | Tape & Reel (TR) | Active | Wirewound | Ceramic | 33 nH | ±5% | - | 500mA | Unshielded | 270mOhm Max | 60 @ 500MHz | 2.05GHz | - | -40°C ~ 125°C | 250 MHz | - | Surface Mount | 0805 | 0.090" L x 0.068" W (2.29mm x 1.73mm) | 0.060" (1.52mm) |
Frequently Asked Questions
What are Fixed Inductors components used for?
Fixed Inductors components are used in a wide range of electronic equipment and systems. Their exact function depends on the device, circuit design and technical requirements of the application.
How do I choose the right Fixed Inductors part?
Compare the manufacturer part number, key specifications, package type, operating conditions, availability and datasheet information. For replacement projects, always verify the critical electrical and mechanical parameters before selecting an alternative.
Can JIEXIN Electronics help source obsolete or hard-to-find Fixed Inductors parts?
Yes. Send us the required manufacturer part number, quantity or BOM. Our sourcing team can help check stock availability, lead time, alternative sourcing options and quotation details.
How can I request pricing and availability?
Submit the part number, manufacturer and required quantity through our RFQ form. JIEXIN Electronics will review your request and provide available stock, pricing and sourcing information.
