Fixed Inductors
Review Fixed Inductors Inductors, Coils, Chokes components in this filtered selection. Compare manufacturer information, availability, pricing, datasheets and key specifications to narrow down suitable parts for your application.
If the exact part or specification you need is not listed, send the manufacturer part number, target parameters and quantity to JIEXIN Electronics for sourcing and quotation support.
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PM5400.682NLTFIXED IND 6.8UH 1.4A 400MOHM SMD |
7,990 |
|
Datasheet | PM5400 | Nonstandard | Tape & Reel (TR) | Active | Molded | - | 6.8 µH | ±20% | 1.4 A | 2A | Shielded | 400mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.138" L x 0.126" W (3.50mm x 3.20mm) | 0.047" (1.20mm) |
|
P0770.152NLFIXED IND 1.5UH 2.6A 50 MOHM SMD |
4,225 |
|
Datasheet | P0770NL | Nonstandard | Tray | Active | Wirewound | - | 1.5 µH | ±20% | 2.6 A | 2.6A | Unshielded | 50mOhm Max | - | - | - | -40°C ~ 130°C | 100 kHz | - | Surface Mount | - | 0.260" L x 0.175" W (6.60mm x 4.45mm) | 0.115" (2.92mm) |
|
BPCI00121280470M00INDUCTOR POWER |
490 |
|
Datasheet | BPCI | Nonstandard | Tape & Reel (TR) | Active | Multilayer | Ferrite | 47 µH | ±20% | 2.5 A | 2.5A | Shielded | 100mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.472" L x 0.472" W (12.00mm x 12.00mm) | 0.315" (8.00mm) |
|
PA5449.153NLTFIXED IND 15UH 4.8A 71 MOHM SMD |
3,996 |
|
Datasheet | PA5449.xxxNLT | Nonstandard | Tape & Reel (TR) | Active | Molded | - | 15 µH | ±20% | 4.8 A | 4.9A | Shielded | 71mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.346" L x 0.323" W (8.80mm x 8.20mm) | 0.157" (4.00mm) |
|
P1169.333NLFIXED IND 33UH 2.2A 94 MOHM SMD |
1,790 |
|
Datasheet | P1169NL | Nonstandard | Tray | Active | Wirewound | - | 33 µH | ±20% | 2.2 A | 2.2A | Shielded | 94mOhm Max | - | 11MHz | - | -40°C ~ 130°C | 100 kHz | - | Surface Mount | - | 0.482" L x 0.482" W (12.24mm x 12.24mm) | 0.177" (4.50mm) |
|
|
P1169.473NLFIXED IND 47UH 1.8A 140 MOHM SMD |
1,790 |
|
Datasheet | P1169NL | Nonstandard | Tray | Active | Wirewound | - | 47 µH | ±20% | 1.8 A | 1.9A | Shielded | 140mOhm Max | - | 9MHz | - | -40°C ~ 130°C | 100 kHz | - | Surface Mount | - | 0.482" L x 0.482" W (12.24mm x 12.24mm) | 0.177" (4.50mm) |
|
|
P1169.153NLFIXED IND 15UH 3.1A 47 MOHM SMD |
1,788 |
|
Datasheet | P1169NL | Nonstandard | Tray | Active | Wirewound | - | 15 µH | ±20% | 3.1 A | 3.3A | Shielded | 47mOhm Max | - | 17MHz | - | -40°C ~ 130°C | 100 kHz | - | Surface Mount | - | 0.482" L x 0.482" W (12.24mm x 12.24mm) | 0.177" (4.50mm) |
|
P1252.222NLFIXED IND 2.2UH 12A 6.1 MOHM SMD |
1,670 |
|
Datasheet | P1252NL | Nonstandard | Tray | Active | Wirewound | - | 2.2 µH | ±20% | 12 A | 20A | Unshielded | 6.1mOhm Max | - | - | - | -40°C ~ 130°C | 100 kHz | - | Surface Mount | - | 0.879" L x 0.596" W (22.33mm x 15.14mm) | 0.295" (7.49mm) |
|
|
P1252.782NLFIXED IND 7.8UH 7.5A 18 MOHM SMD |
1,670 |
|
Datasheet | P1252NL | Nonstandard | Tray | Active | Wirewound | - | 7.8 µH | ±20% | 7.5 A | 11A | Unshielded | 18mOhm Max | - | - | - | -40°C ~ 130°C | 100 kHz | - | Surface Mount | - | 0.879" L x 0.596" W (22.33mm x 15.14mm) | 0.295" (7.49mm) |
|
|
P1252.472NLFIXED IND 4.7UH 8.4A 14 MOHM SMD |
1,590 |
|
Datasheet | P1252NL | Nonstandard | Tray | Active | Wirewound | - | 4.7 µH | ±20% | 8.4 A | 13A | Unshielded | 14mOhm Max | - | - | - | -40°C ~ 130°C | 100 kHz | - | Surface Mount | - | 0.879" L x 0.596" W (22.33mm x 15.14mm) | 0.295" (7.49mm) |
Frequently Asked Questions
What are Fixed Inductors components used for?
Fixed Inductors components are used in a wide range of electronic equipment and systems. Their exact function depends on the device, circuit design and technical requirements of the application.
How do I choose the right Fixed Inductors part?
Compare the manufacturer part number, key specifications, package type, operating conditions, availability and datasheet information. For replacement projects, always verify the critical electrical and mechanical parameters before selecting an alternative.
Can JIEXIN Electronics help source obsolete or hard-to-find Fixed Inductors parts?
Yes. Send us the required manufacturer part number, quantity or BOM. Our sourcing team can help check stock availability, lead time, alternative sourcing options and quotation details.
How can I request pricing and availability?
Submit the part number, manufacturer and required quantity through our RFQ form. JIEXIN Electronics will review your request and provide available stock, pricing and sourcing information.
