TVS Diodes
Explore TVS Diodes parts from multiple manufacturers, with model information, availability, datasheets and technical specifications for engineering and purchasing.
For parts that are not shown in the list, send the manufacturer part number, quantity or BOM to JIEXIN Electronics. Our team can assist with availability checks and quotation support.
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Type | Unidirectional Channels | Bidirectional Channels | Voltage - Reverse Standoff (Typ) | Voltage - Breakdown (Min) | Voltage - Clamping (Max) @ Ipp | Current - Peak Pulse (10/1000µs) | Power - Peak Pulse | Power Line Protection | Applications | Capacitance @ Frequency | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SMA6J28A R3GTVS DIODE 28VWM 44VC DO214AC |
1,173 |
|
Datasheet | DO-214AC, SMA | SMA6J | Tape & Reel (TR) | Discontinued at Digi-Key | Zener | 1 | - | 28V | 31.1V | 44V | 13.6A | 600W | No | General Purpose | - | -55°C ~ 175°C (TJ) | - | - | Surface Mount | DO-214AC (SMA) |
|
SM30T6.8CAYTVS DIODE 5VWM 9.2VC SMC |
929 |
|
Datasheet | DO-214AB, SMC | SM30TY, TRANSIL™ | Tape & Reel (TR) | Active | Zener | - | 1 | 5V | 6.45V | 9.2V | 327A | 3000W (3kW) | No | - | - | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SMC |
|
TPSMD10ATVS DIODE 10VWM 17VC DO214AB |
529 |
|
Datasheet | DO-214AB, SMC | TPSMD | Tape & Reel (TR) | Active | Zener | 1 | - | 10V | 11.1V | 17V | 176.5A | 3000W (3kW) | No | - | - | -65°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | DO-214AB (SMCJ) |
|
3.0SMCJ54A-AU_R1_000A1SURFACE MOUNT TRANSIENT VOLTAGE |
700 |
|
Datasheet | DO-214AB, SMC | - | Tape & Reel (TR) | Active | Zener | 1 | - | 54V | 60V | 87.1V | 34.4A | 3000W (3kW) | No | - | - | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | DO-214AB (SMC) |
|
1.5KE27AHE3_A/CTVS DIODE 23.1VWM 37.5VC 1.5KE |
611 |
|
Datasheet | DO-201AA, DO-27, Axial | TransZorb® | Tape & Reel (TR) | Obsolete | Zener | 1 | - | 23.1V | 25.7V | 37.5V | 40A | 1500W (1.5kW) | No | - | - | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Through Hole | 1.5KE |
|
MAX3205EETE+TVS DIODE 16TQFN |
6,000 |
|
Datasheet | 16-WFQFN Exposed Pad | - | Bulk | Obsolete | Steering (Rail to Rail) | 6 | - | - | - | - | - | - | Yes | General Purpose | - | -40°C ~ 125°C (TA) | - | - | Surface Mount | 16-TQFN (3x3) |
|
TPSMC130ATVS 1.5KW 130V 5%UNI DO-214AB |
6,000 |
|
Datasheet | DO-214AB, SMC | TPSMC | Tape & Reel (TR) | Active | Zener | 1 | - | 111.15V | 123.5V | 179V | 8.5A | 1500W (1.5kW) | No | Telecom | - | -65°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SMC |
|
|
TPSMC220ATVS 1.5KW 220V 5%UNI DO-214AB |
6,000 |
|
Datasheet | DO-214AB, SMC | TPSMC | Tape & Reel (TR) | Active | Zener | 1 | - | 188.1V | 209V | 328V | 4.6A | 1500W (1.5kW) | No | Telecom | - | -65°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SMC |
|
|
TPSMC180ATVS 1.5KW 180V 5%UNI DO-214AB |
5,834 |
|
Datasheet | DO-214AB, SMC | TPSMC | Tape & Reel (TR) | Active | Zener | 1 | - | 153.9V | 171V | 246V | 6.2A | 1500W (1.5kW) | No | Telecom | - | -65°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SMC |
|
|
TPSMC160ATVS 1.5KW 160V 5%UNI DO-214AB |
5,830 |
|
Datasheet | DO-214AB, SMC | TPSMC | Tape & Reel (TR) | Active | Zener | 1 | - | 136.8V | 152V | 219V | 6.9A | 1500W (1.5kW) | No | Telecom | - | -65°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SMC |
|
|
TPSMC120ATVS 1.5KW 120V 5%UNI DO-214AB |
5,133 |
|
Datasheet | DO-214AB, SMC | TPSMC | Tape & Reel (TR) | Active | Zener | 1 | - | 102.6V | 114V | 165V | 9.2A | 1500W (1.5kW) | No | Telecom | - | -65°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SMC |
|
|
TPSMC200ATVS 1.5KW 200V 5%UNI DO-214AB |
4,924 |
|
Datasheet | DO-214AB, SMC | TPSMC | Tape & Reel (TR) | Active | Zener | 1 | - | 171V | 190V | 274V | 5.5A | 1500W (1.5kW) | No | Telecom | - | -65°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SMC |
|
|
TPSMC150ATVS 1.5KW 150V 5%UNI DO-214AB |
4,823 |
|
Datasheet | DO-214AB, SMC | TPSMC | Tape & Reel (TR) | Active | Zener | 1 | - | 128.25V | 142.5V | 207V | 7.3A | 1500W (1.5kW) | No | Telecom | - | -65°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SMC |
|
|
TPSMC250ATVS 1.5KW 250V 5%UNI DO-214AB |
3,939 |
|
Datasheet | DO-214AB, SMC | TPSMC | Tape & Reel (TR) | Active | Zener | 1 | - | 213.75V | 237.5V | 344V | 4.4A | 1500W (1.5kW) | No | Telecom | - | -65°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SMC |
|
MAX3205EABL+TTVS DIODE 9UCSP |
7,895 |
|
Datasheet | 9-WFBGA, WLBGA | - | Tape & Reel (TR) | Obsolete | Steering (Rail to Rail) | 6 | - | - | - | - | - | - | Yes | General Purpose | - | -40°C ~ 125°C (TA) | - | - | Surface Mount | 9-WLP |
|
MSMBJ6.0ATVS DIODE 6VWM 10.3VC SMBJ |
553 |
|
Datasheet | DO-214AA, SMB | - | Bulk | Active | Zener | 1 | - | 6V | 6.67V | 10.3V | 58.3A | 600W | No | General Purpose | - | -65°C ~ 150°C (TJ) | Military | MIL-PRF-19500 | Surface Mount | DO-214AA (SMBJ) |
|
3.0SMCJ6.0CA_R1_00001SURFACE MOUNT TRANSIENT VOLTAGE |
795 |
|
Datasheet | DO-214AB, SMC | - | Tape & Reel (TR) | Active | Zener | - | 1 | 6V | 6.67V | 10.3V | 291.3A | 3000W (3kW) | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | DO-214AB (SMC) |
|
PESD3USB3B/CXTVS DIODE 4VWM 3.7VC DSN0603-2 |
5,474 |
|
Datasheet | 15-UFBGA, WLCSP | PESDxUSB3B/C | Tape & Reel (TR) | Obsolete | Zener | - | 1 | 4V (Max) | 6V | - | 9.5A (8/20µs) | - | No | HDMI, USB | 0.29pF @ 1MHz | -40°C ~ 125°C (TA) | - | - | Surface Mount | 15-WLCSP (2.37x1.17) |
|
SMLJ6.5CA-TPTVS DIODE 6.5VWM 11.2VC DO214AB |
4,684 |
|
Datasheet | DO-214AB, SMC | - | Tape & Reel (TR) | Active | Zener | - | 1 | 6.5V | 7.22V | 11.2V | 267.9A | 3000W (3kW) | No | General Purpose | - | -55°C ~ 175°C (TJ) | - | - | Surface Mount | DO-214AB (SMC) |
|
|
PESD3USB3S/CXTVS DIODE 15WLCSP |
4,380 |
|
Datasheet | 15-UFBGA, WLCSP | - | Tape & Reel (TR) | Obsolete | Zener | 2 | - | - | 6V | - | 8A (8/20µs) | - | No | HDMI, USB | 0.45pF @ 1MHz | -40°C ~ 85°C (TA) | - | - | Surface Mount | 15-WLCSP (2.37x1.17) |
Frequently Asked Questions
What are TVS Diodes components used for?
TVS Diodes components are used in a wide range of electronic equipment and systems. Their exact function depends on the device, circuit design and technical requirements of the application.
How do I choose the right TVS Diodes part?
Compare the manufacturer part number, key specifications, package type, operating conditions, availability and datasheet information. For replacement projects, always verify the critical electrical and mechanical parameters before selecting an alternative.
Can JIEXIN Electronics help source obsolete or hard-to-find TVS Diodes parts?
Yes. Send us the required manufacturer part number, quantity or BOM. Our sourcing team can help check stock availability, lead time, alternative sourcing options and quotation details.
How can I request pricing and availability?
Submit the part number, manufacturer and required quantity through our RFQ form. JIEXIN Electronics will review your request and provide available stock, pricing and sourcing information.
