TVS Diodes
Explore TVS Diodes parts from multiple manufacturers, with model information, availability, datasheets and technical specifications for engineering and purchasing.
For parts that are not shown in the list, send the manufacturer part number, quantity or BOM to JIEXIN Electronics. Our team can assist with availability checks and quotation support.
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Type | Unidirectional Channels | Bidirectional Channels | Voltage - Reverse Standoff (Typ) | Voltage - Breakdown (Min) | Voltage - Clamping (Max) @ Ipp | Current - Peak Pulse (10/1000µs) | Power - Peak Pulse | Power Line Protection | Applications | Capacitance @ Frequency | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
P6SMBJ56ATVS DIODE 47.8VWM 77VC DO214AA |
6,773 |
|
Datasheet | DO-214AA, SMB | P6SMBJ | Tape & Reel (TR) | Obsolete | Zener | 1 | - | 47.8V | 53.2V | 77V | 7.9A | 600W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | DO-214AA (SMBJ) |
|
|
P6SMBJ62ATVS DIODE 53VWM 85VC DO214AA |
8,517 |
|
Datasheet | DO-214AA, SMB | P6SMBJ | Tape & Reel (TR) | Obsolete | Zener | 1 | - | 53V | 58.9V | 85V | 7.2A | 600W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | DO-214AA (SMBJ) |
|
|
P6SMBJ68ATVS DIODE 58.1VWM 92VC DO214AA |
4,265 |
|
Datasheet | DO-214AA, SMB | P6SMBJ | Tape & Reel (TR) | Obsolete | Zener | 1 | - | 58.1V | 64.6V | 92V | 6.6A | 600W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | DO-214AA (SMBJ) |
|
P6SMBJ75ATVS SMB 75V 600W UNIDIR |
9,773 |
|
Datasheet | DO-214AA, SMB | P6SMBJ | Tape & Reel (TR) | Obsolete | Zener | 1 | - | 64.1V | 71.3V | 103V | 5.9A | 600W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | DO-214AA (SMBJ) |
|
|
P6SMBJ82ATVS DIODE 70.1VWM 113VC DO214AA |
2,070 |
|
Datasheet | DO-214AA, SMB | P6SMBJ | Tape & Reel (TR) | Obsolete | Zener | 1 | - | 70.1V | 77.9V | 113V | 5.4A | 600W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | DO-214AA (SMBJ) |
|
|
P6SMBJ91ATVS DIODE 77.8VWM 125VC DO214AA |
3,032 |
|
Datasheet | DO-214AA, SMB | P6SMBJ | Tape & Reel (TR) | Obsolete | Zener | 1 | - | 77.8V | 86.5V | 125V | 4.9A | 600W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | DO-214AA (SMBJ) |
|
|
P6SMBJ100ATVS SMB 100V 600W UNIDIR |
6,951 |
|
Datasheet | DO-214AA, SMB | P6SMBJ | Tape & Reel (TR) | Obsolete | Zener | 1 | - | 85.5V | 95V | 137V | 4.5A | 600W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | DO-214AA (SMBJ) |
|
|
P6SMBJ110ATVS SMB 110V 600W UNIDIR |
7,659 |
|
Datasheet | DO-214AA, SMB | P6SMBJ | Tape & Reel (TR) | Obsolete | Zener | 1 | - | 94V | 105V | 152V | 4A | 600W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | DO-214AA (SMBJ) |
|
|
P6SMBJ120ATVS SMB 120V 600W UNIDIR |
7,443 |
|
Datasheet | DO-214AA, SMB | P6SMBJ | Tape & Reel (TR) | Obsolete | Zener | 1 | - | 102V | 114V | 165V | 3.7A | 600W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | DO-214AA (SMBJ) |
|
|
P6SMBJ130ATVS SMB 130V 600W UNIDIR |
4,240 |
|
Datasheet | DO-214AA, SMB | P6SMBJ | Tape & Reel (TR) | Obsolete | Zener | 1 | - | 111V | 124V | 179V | 3.4A | 600W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | DO-214AA (SMBJ) |
|
|
P6SMBJ150ATVS SMB 150V 600W UNIDIR |
4,872 |
|
Datasheet | DO-214AA, SMB | P6SMBJ | Tape & Reel (TR) | Obsolete | Zener | 1 | - | 128V | 143V | 207V | 2.9A | 600W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | DO-214AA (SMBJ) |
|
P6SMBJ170ATVS SMB 170V 600W UNIDIR |
9,641 |
|
Datasheet | DO-214AA, SMB | P6SMBJ | Tape & Reel (TR) | Obsolete | Zener | 1 | - | 145V | 162V | 234V | 2.6A | 600W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | DO-214AA (SMBJ) |
|
|
P6SMBJ180ATVS DIODE 154VWM 246VC DO214AA |
7,590 |
|
Datasheet | DO-214AA, SMB | P6SMBJ | Tape & Reel (TR) | Obsolete | Zener | 1 | - | 154V | 171V | 246V | 2.5A | 600W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | DO-214AA (SMBJ) |
|
SMF26AT1GTVS DIODE 26VWM 42.1VC SOD123FL |
7,028 |
|
Datasheet | SOD-123F | SMF | Tape & Reel (TR) | Obsolete | Zener | 1 | - | 26V | 28.9V | 42.1V | 4.8A | 200W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOD-123FL |
|
VESD05A1B-02Z-GS08TVS DIODE 5VWM 11VC SOD923 |
2,370 |
|
Datasheet | SOD-923 | - | Tape & Reel (TR) | Obsolete | Zener | 1 | - | 5V (Max) | 6V | 11V | 3A (8/20µs) | 33W | No | General Purpose | 19pF @ 1MHz | -40°C ~ 125°C (TJ) | - | - | Surface Mount | SOD-923 |
|
AOZ8001KITVS DIODE 5VWM 14.5VC SC89-6 |
4,767 |
|
Datasheet | SOT-563, SOT-666 | - | Tape & Reel (TR) | Obsolete | Steering (Rail to Rail) | 2 | - | 5V | 6.6V | 14.5V | 5A (8/20µs) | - | Yes | Ethernet | - | -40°C ~ 125°C (TJ) | - | - | Surface Mount | SC-89-6 |
|
ESD0P2RF02LRHE6327XTSA1TVS DIODE 5.3VWM 21VC TSLP-2 |
6,725 |
|
Datasheet | SOD-882 | - | Tape & Reel (TR) | Obsolete | Zener | - | 1 | 5.3V (Max) | 7V | 21V | 3A (8/20µs) | - | No | RF Antenna | 0.23pF @ 1MHz | -55°C ~ 125°C (TJ) | - | - | Surface Mount | PG-TSLP-2-17 |
|
RSB27F2T106TVS DIODE 24VWM UMD3 |
9,325 |
|
Datasheet | SC-70, SOT-323 | - | Tape & Reel (TR) | Not For New Designs | Zener | - | 2 | 24V | 26.2V | - | - | - | No | General Purpose | - | - | - | - | Surface Mount | UMD3 |
|
SMAJ15AHE3/61TVS DIODE 15VWM 24.4VC DO214AC |
8,451 |
|
Datasheet | DO-214AC, SMA | TransZorb® | Tape & Reel (TR) | Discontinued at Digi-Key | Zener | 1 | - | 15V | 16.7V | 24.4V | 16.4A | 400W | No | - | - | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | DO-214AC (SMA) |
|
AOZ8302CI-05TVS DIODE 5VWM 14VC SOT23A-3 |
4,279 |
|
Datasheet | TO-236-3, SC-59, SOT-23-3 | - | Tape & Reel (TR) | Obsolete | Zener | 2 | - | 5V (Max) | 6V | 14V | 32A (8/20µs) | 432W | No | Ethernet, Telecom | 25pF @ 1MHz | -40°C ~ 85°C (TJ) | - | - | Surface Mount | SOT-23A-3 |
Frequently Asked Questions
What are TVS Diodes components used for?
TVS Diodes components are used in a wide range of electronic equipment and systems. Their exact function depends on the device, circuit design and technical requirements of the application.
How do I choose the right TVS Diodes part?
Compare the manufacturer part number, key specifications, package type, operating conditions, availability and datasheet information. For replacement projects, always verify the critical electrical and mechanical parameters before selecting an alternative.
Can JIEXIN Electronics help source obsolete or hard-to-find TVS Diodes parts?
Yes. Send us the required manufacturer part number, quantity or BOM. Our sourcing team can help check stock availability, lead time, alternative sourcing options and quotation details.
How can I request pricing and availability?
Submit the part number, manufacturer and required quantity through our RFQ form. JIEXIN Electronics will review your request and provide available stock, pricing and sourcing information.
