TVS Diodes
Explore TVS Diodes parts from multiple manufacturers, with model information, availability, datasheets and technical specifications for engineering and purchasing.
For parts that are not shown in the list, send the manufacturer part number, quantity or BOM to JIEXIN Electronics. Our team can assist with availability checks and quotation support.
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Type | Unidirectional Channels | Bidirectional Channels | Voltage - Reverse Standoff (Typ) | Voltage - Breakdown (Min) | Voltage - Clamping (Max) @ Ipp | Current - Peak Pulse (10/1000µs) | Power - Peak Pulse | Power Line Protection | Applications | Capacitance @ Frequency | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ESDSLC5V0D9B-TPTVS DIODE 5VWM SOD923 |
3,127 |
|
Datasheet | SOD-923 | - | Tape & Reel (TR) | Obsolete | Zener | - | 1 | 5V (Max) | 5.6V | - | - | 80W | No | General Purpose | 0.6pF @ 1MHz | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOD-923 |
|
CPDER5V0U-HFTVS DIODE 5VWM 12.5VC 0503 |
8,371 |
|
Datasheet | 0503 (1308 Metric) | - | Tape & Reel (TR) | Last Time Buy | Zener | 1 | - | 5V | 6V | 12.5V | 16A (8/20µs) | 200W | No | General Purpose | 90pF @ 1MHz | - | - | - | Surface Mount | 0503/SOD-723F |
|
LXES03BAA1-131TVS DIODE 5.5VWM SMD |
6,472 |
|
Datasheet | 0201 (0603 Metric) | - | Tape & Reel (TR) | Obsolete | Zener | - | 1 | 5.5V | 6V | - | - | - | No | General Purpose | - | -40°C ~ 85°C (TA) | - | - | Surface Mount | - |
|
NS6A13AFT3GTVS DIODE 13VWM 21.5VC SMA-FL |
5,249 |
|
Datasheet | DO-221AC, SMA Flat Leads | - | Tape & Reel (TR) | Obsolete | Zener | 1 | - | 13V | 14.4V | 21.5V | 27.9A | 600W | No | General Purpose | 1160pF @ 1MHz | -65°C ~ 150°C (TJ) | - | - | Surface Mount | SMA-FL |
|
NS6A5.0AFT3GTVS DIODE 5VWM 9.2VC SMA-FL |
4,828 |
|
Datasheet | DO-221AC, SMA Flat Leads | - | Tape & Reel (TR) | Obsolete | Zener | 1 | - | 5V | 6.4V | 9.2V | 65.2A | 600W | No | General Purpose | 2700pF @ 1MHz | -65°C ~ 150°C (TJ) | - | - | Surface Mount | SMA-FL |
|
RCLAMP2656P.TGTTVS DIODE 5VWM 20VC SLP2018P6 |
6,393 |
|
Datasheet | 6-UFDFN Exposed Pad | RailClamp® | Tape & Reel (TR) | Active | Steering (Rail to Rail) | 3 | - | 5V (Max) | 6.5V | 20V | 3A (8/20µs) | 60W | Yes | USB OTG | 0.28pF @ 1MHz | -55°C ~ 125°C (TJ) | - | - | Surface Mount | SLP2018P6 |
;;2.jpg "SMA4F12AY")
|
SMA4F12AYTVS DIODE 12VWM 19.9VC SMAFLAT |
7,484 |
|
Datasheet | DO-221AC, SMA Flat Leads | SMA4F | Tape & Reel (TR) | Obsolete | Zener | 1 | - | 12V | 13.3V | 19.9V | 20.1A | 400W | No | - | - | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SMAflat |
|
|
SMA4F18AYTVS DIODE 18VWM 29.2VC SMAFLAT |
8,241 |
|
Datasheet | DO-221AC, SMA Flat Leads | SMA4F | Tape & Reel (TR) | Obsolete | Zener | 1 | - | 18V | 20V | 29.2V | 13.7A | 400W | No | - | - | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SMAflat |
|
|
SMA4F6.0AYTVS DIODE 6VWM 10.3VC SMAFLAT |
8,753 |
|
Datasheet | DO-221AC, SMA Flat Leads | SMA4F | Tape & Reel (TR) | Obsolete | Zener | 1 | - | 6V | 6.7V | 10.3V | 38.8A | 400W | No | - | - | -55°C ~ 175°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SMAflat |
|
CPDV8V0-HFTVS DIODE 8VWM 24VC SOD323 |
9,043 |
|
Datasheet | SC-76, SOD-323 | - | Tape & Reel (TR) | Active | Steering (Rail to Rail) | - | 1 | 8V (Max) | 8.5V | 24V | 18A (8/20µs) | 350W | Yes | General Purpose | - | -55°C ~ 150°C (TA) | - | - | Surface Mount | SOD-323 |
|
|
CPDV15V0-HFTVS DIODE 15VWM 31.8VC SOD323 |
8,957 |
|
Datasheet | SC-76, SOD-323 | - | Tape & Reel (TR) | Active | Steering (Rail to Rail) | - | 1 | 15V (Max) | 16.7V | 31.8V | 10A (8/20µs) | 350W | Yes | General Purpose | - | -55°C ~ 150°C (TA) | - | - | Surface Mount | SOD-323 |
|
|
CPDV24V0-HFTVS DIODE 24VWM 56VC SOD323 |
7,657 |
|
Datasheet | SC-76, SOD-323 | - | Tape & Reel (TR) | Active | Steering (Rail to Rail) | - | 1 | 24V (Max) | 26.7V | 56V | 6A (8/20µs) | 350W | Yes | General Purpose | - | -55°C ~ 150°C (TA) | - | - | Surface Mount | SOD-323 |
|
|
CPDV3V0-HFTVS DIODE 3VWM 20VC SOD323 |
9,415 |
|
Datasheet | SC-76, SOD-323 | - | Tape & Reel (TR) | Active | Steering (Rail to Rail) | - | 1 | 3V (Max) | 4V | 20V | 20A (8/20µs) | 350W | Yes | General Purpose | - | -55°C ~ 150°C (TA) | - | - | Surface Mount | SOD-323 |
|
|
CPDV5V0-HFTVS DIODE 5VWM 20VC SOD323 |
6,104 |
|
Datasheet | SC-76, SOD-323 | - | Tape & Reel (TR) | Active | Steering (Rail to Rail) | - | 1 | 5V (Max) | 6V | 20V | 18A (8/20µs) | 350W | Yes | General Purpose | - | -55°C ~ 150°C (TA) | - | - | Surface Mount | SOD-323 |
|
|
CPDV12V0-HFTVS DIODE 12VWM 28.6VC SOD323 |
8,275 |
|
Datasheet | SC-76, SOD-323 | - | Tape & Reel (TR) | Active | Steering (Rail to Rail) | - | 1 | 12V (Max) | 13.3V | 28.6V | 12A (8/20µs) | 350W | Yes | General Purpose | - | -55°C ~ 150°C (TA) | - | - | Surface Mount | SOD-323 |
|
EMZT6.8EFHT2RTVS DIODE 3.5VWM EMD5 |
5,063 |
|
Datasheet | SOT-553 | - | Tape & Reel (TR) | Not For New Designs | Steering (Rail to Rail) | 4 | - | 3.5V | 6.47V | - | - | - | No | - | 7pF @ 1MHz | 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | EMD5 |
|
P1CH17A_R1_00001SURFACE MOUNT TRANSIENT VOLTAGE |
6,492 |
|
Datasheet | SC-90, SOD-323F | - | Tape & Reel (TR) | Active | Zener | 1 | - | 17V | 18.9V | 27.6V | 5.3A | 150W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOD-323HE |
|
|
P1CH8.5A_R1_00001SURFACE MOUNT TRANSIENT VOLTAGE |
7,273 |
|
Datasheet | SC-90, SOD-323F | - | Tape & Reel (TR) | Active | Zener | 1 | - | 8.5V | 9.44V | 14.4V | 10.4A | 150W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOD-323HE |
|
|
P1CH6.5A_R1_00001SURFACE MOUNT TRANSIENT VOLTAGE |
6,888 |
|
Datasheet | SC-90, SOD-323F | - | Tape & Reel (TR) | Active | Zener | 1 | - | 6.5V | 7.22V | 11.2V | 13.4A | 150W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOD-323HE |
|
|
P1CH12A_R1_00001SURFACE MOUNT TRANSIENT VOLTAGE |
2,620 |
|
Datasheet | SC-90, SOD-323F | - | Tape & Reel (TR) | Active | Zener | 1 | - | 12V | 13.3V | 19.9V | 7.5A | 150W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOD-323HE |
Frequently Asked Questions
What are TVS Diodes components used for?
TVS Diodes components are used in a wide range of electronic equipment and systems. Their exact function depends on the device, circuit design and technical requirements of the application.
How do I choose the right TVS Diodes part?
Compare the manufacturer part number, key specifications, package type, operating conditions, availability and datasheet information. For replacement projects, always verify the critical electrical and mechanical parameters before selecting an alternative.
Can JIEXIN Electronics help source obsolete or hard-to-find TVS Diodes parts?
Yes. Send us the required manufacturer part number, quantity or BOM. Our sourcing team can help check stock availability, lead time, alternative sourcing options and quotation details.
How can I request pricing and availability?
Submit the part number, manufacturer and required quantity through our RFQ form. JIEXIN Electronics will review your request and provide available stock, pricing and sourcing information.
