Surge Protection Devices (SPDs)
Explore Surge Protection Devices (SPDs) parts from multiple manufacturers, with model information, availability, datasheets and technical specifications for engineering and purchasing.
For parts that are not shown in the list, send the manufacturer part number, quantity or BOM to JIEXIN Electronics. Our team can assist with availability checks and quotation support.
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Form | Number of Poles | Voltage - Continuous Operating (Max) (MCOV) | Current - Discharge (Nom) (8/20µS) | Current - Discharge (Max) (8/20µS) | Operating Temperature | Voltage - Protection Rating (VPR) | Voltage - Protection Level (VP) (2416) | Operating Temperature | Features | Mounting Type | Approval Agency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
BPMA510ULSPD TYPE 2 1.02KV MCOV 4 POLE |
9,290 |
|
Datasheet | BUSSMANN | Bulk | Active | Type 2 | Base + Module | 4 | 1.02kV | 20 kA | 50 kA | 200 kA | 3 kV | - | -40°C ~ 90°C | Visual Life Indicator | DIN Rail | - |
|
|
SPD2-300-MSPD TYP 1/TYP 2 300V MCOV 1 POLE |
5,781 |
|
Datasheet | SPD2 1P+1 | Bulk | Active | Type 1, Type 2 | Module Only | 1 | 300V | 20 kA | 50 kA | 150 kA | 900 V | 1.5 kV | -40°C ~ 80°C | Thermally Protected, Visual Life Indicator | DIN Rail | CE, cURus, UL, VDE |
|
2025050000SPD TYPE 1 385VAC MCOV 1 POLE |
7,034 |
|
Datasheet | VPU | Box | Obsolete | Type 1 | Base + Module | 1 | 385VAC | 20 kA | 40 kA | 200 kA | - | - | -40°C ~ 70°C | - | Chassis Mount | CE, cURus |
|
|
1260-2SMG-480SPD 600VAC MCOV 2 POLE |
7,829 |
|
Datasheet | 1260 | Box | Active | - | Base + Module | 2 | 600VAC | 25 kA | 100 kA | 50 kA | - | - | -40°C ~ 85°C | Remote Signaling Contacts, Visual Life Indicator | DIN Rail | - |
|
|
1260-2SMG-690SPD 750VAC MCOV 2 POLE |
8,044 |
|
Datasheet | 1260 | Box | Active | - | Base + Module | 2 | 750VAC | 25 kA | 100 kA | 50 kA | - | - | -40°C ~ 85°C | Remote Signaling Contacts, Visual Life Indicator | DIN Rail | - |
|
|
2800755SPD 36VDC MCOV 1 POLE |
6,733 |
|
Datasheet | PT | Bulk | Active | - | Module Only | 1 | 36VDC | 100 A | 10 kA | - | - | 1.3 kV | -40°C ~ 80°C | - | Base Mount | - |
|
|
AGDN1000PV30LRSPD TYPE 1 1.5KVAC MCOV 1 POLE |
7,536 |
|
Datasheet | - | Bulk | Active | Type 1 | Base + Module | 1 | 1.5kVAC | 20 kA | - | 50 kA | 2.5 kV | - | -40°C ~ 85°C | Visual Life Indicator | DIN Rail | UL |
|
|
SPD2-480-MSPD TYP 1/TYP 2 480V MCOV 1 POLE |
7,478 |
|
Datasheet | SPD2 3P+0 | Bulk | Active | Type 1, Type 2 | Module Only | 1 | 480V | 20 kA | 50 kA | 200 kA | 1.5 kV | 2.3 kV | -40°C ~ 80°C | Thermally Protected, Visual Life Indicator | DIN Rail | CE, cURus, UL, VDE |
|
|
SPD2-150-3P0SPD TYP 1/TYP 2 150V MCOV 3 POLE |
4,785 |
|
Datasheet | SPD2 3P+0 | Bulk | Active | Type 1, Type 2 | Base + Module | 3 | 150V | 20 kA | 50 kA | 200 kA | 600 V | 1.25 kV | -40°C ~ 80°C | Thermally Protected, Visual Life Indicator | DIN Rail | CE, cURus, UL, VDE |
|
|
SPD2-300-3P0SPD TYP 1/TYP 2 300V MCOV 3 POLE |
7,489 |
|
Datasheet | SPD2 3P+0 | Bulk | Active | Type 1, Type 2 | Base + Module | 3 | 300V | 20 kA | 50 kA | 150 kA | 900 V | 1.5 kV | -40°C ~ 80°C | Thermally Protected, Visual Life Indicator | DIN Rail | CE, cURus, UL, VDE |
|
|
BSPH2A150D150LVRSPD TYPE 3/TYPE 4 150VAC MCOV |
5,091 |
|
Datasheet | BSPH | Bulk | Active | Type 3, Type 4 | Base + Module | 2 | 150VAC | 2 kA | 4 kA | 6 kA | - | - | -40°C ~ 80°C | - | DIN Rail | CSA, KEMA, UL |
|
|
SPD2-350-3P0SPD TYP 1/TYP 2 350V MCOV 3 POLE |
8,988 |
|
Datasheet | SPD2 3P+0 | Bulk | Active | Type 1, Type 2 | Base + Module | 3 | 350V | 20 kA | 50 kA | 200 kA | 1 kV | 1.75 kV | -40°C ~ 80°C | Thermally Protected, Visual Life Indicator | DIN Rail | CE, cURus, UL, VDE |
|
|
SPH50SP3240DLGSPD TYPE 1 |
3,670 |
|
Datasheet | * | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
SPD2-480-3P0SPD TYP 1/TYP 2 480V MCOV 3 POLE |
5,384 |
|
Datasheet | SPD2 3P+0 | Bulk | Active | Type 1, Type 2 | Base + Module | 3 | 480V | 20 kA | 50 kA | 200 kA | 1.5 kV | 2.3 kV | -40°C ~ 80°C | Thermally Protected, Visual Life Indicator | DIN Rail | CE, cURus, UL, VDE |
|
|
2800769SPD 180VDC MCOV 1 POLE |
5,912 |
|
Datasheet | PT | Bulk | Active | - | Base + Module | 1 | 180VDC | 10 kA | 20 kA | - | - | 700 V | -40°C ~ 70°C | - | DIN Rail | cUL, UL |
|
|
SPD2-550-MSPD TYP 1/TYP 2 550V MCOV 1 POLE |
3,406 |
|
Datasheet | SPD2 2P+0 | Bulk | Active | Type 1, Type 2 | Module Only | 1 | 550V | 20 kA | 50 kA | 200 kA | 2 kV | 2.5 kV | -40°C ~ 80°C | Thermally Protected, Visual Life Indicator | DIN Rail | CE, cURus, UL, VDE |
|
|
2801491SPD TYP 1/TYP 2 75VDC MCOV 1POLE |
5,296 |
|
Datasheet | VAL-MS | Bulk | Active | Type 1, Type 2 | Base + Module | 1 | 75VDC | 12.5 kA | 50 kA | - | - | 700 V | -40°C ~ 80°C | - | DIN Rail | - |
|
|
2730650000SPD TYPE 2 350VAC MCOV 2 POLE |
6,263 |
|
Datasheet | - | Box | Active | Type 2 | Base + Module | 2 | 350VAC | 20 kA | 50 kA | 200 kA | 1 kV | - | -40°C ~ 85°C | - | DIN Rail | CE, cULus, VDE |
|
|
2730630000SPD TYPE 2 350VAC MCOV 2 POLE |
5,426 |
|
Datasheet | - | Box | Active | Type 2 | Base + Module | 2 | 350VAC | 20 kA | 50 kA | 200 kA | 1 kV | - | -40°C ~ 85°C | - | DIN Rail | CE, cULus, VDE |
|
|
SPD2-075-MSPD TYPE 1/TYP 2 75V MCOV 1 POLE |
6,340 |
|
Datasheet | SPD2 1P+1 | Bulk | Active | Type 1, Type 2 | Module Only | 1 | 75V | 20 kA | 50 kA | 100 kA | 330 V | 800 V | -40°C ~ 80°C | Thermally Protected, Visual Life Indicator | DIN Rail | CE, cURus, UL, VDE |
Frequently Asked Questions
What are Surge Protection Devices (SPDs) components used for?
Surge Protection Devices (SPDs) components are used in a wide range of electronic equipment and systems. Their exact function depends on the device, circuit design and technical requirements of the application.
How do I choose the right Surge Protection Devices (SPDs) part?
Compare the manufacturer part number, key specifications, package type, operating conditions, availability and datasheet information. For replacement projects, always verify the critical electrical and mechanical parameters before selecting an alternative.
Can JIEXIN Electronics help source obsolete or hard-to-find Surge Protection Devices (SPDs) parts?
Yes. Send us the required manufacturer part number, quantity or BOM. Our sourcing team can help check stock availability, lead time, alternative sourcing options and quotation details.
How can I request pricing and availability?
Submit the part number, manufacturer and required quantity through our RFQ form. JIEXIN Electronics will review your request and provide available stock, pricing and sourcing information.
