TVS Diodes
Explore TVS Diodes parts from multiple manufacturers, with model information, availability, datasheets and technical specifications for engineering and purchasing.
For parts that are not shown in the list, send the manufacturer part number, quantity or BOM to JIEXIN Electronics. Our team can assist with availability checks and quotation support.
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Type | Unidirectional Channels | Bidirectional Channels | Voltage - Reverse Standoff (Typ) | Voltage - Breakdown (Min) | Voltage - Clamping (Max) @ Ipp | Current - Peak Pulse (10/1000µs) | Power - Peak Pulse | Power Line Protection | Applications | Capacitance @ Frequency | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SA11AGTVS DIODE 11VWM 18.2VC AXIAL |
4,375 |
|
Datasheet | DO-204AC, DO-15, Axial | MiniMosorb™ | Bulk | Obsolete | Zener | 1 | - | 11V | 12.2V | 18.2V | 27.4A | 500W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Through Hole | Axial |
|
GSM4F40CATVS, BI-DIR, 400W, 40V, ESGA (SO |
6,000 |
|
Datasheet | SOD-123F | - | Tape & Reel (TR) | Active | Zener | - | 1 | 40V | 44.4V | 64.5V | 6.2A | 400W | No | Telecom | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOD-123FL |
|
|
GSMF58CATVS, BI-DIR, 200W, 58V, ESGA (SO |
5,890 |
|
Datasheet | SOD-123F | GSMF58CA | Tape & Reel (TR) | Active | Zener | - | 1 | 58V | 64.4V | 93.6V | 2.14A | 200W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOD-123FL |
|
|
GSMF3.3CATVS, BI-DIR, 200W, 3.3V, ESGA (S |
5,624 |
|
Datasheet | SOD-123F | - | Tape & Reel (TR) | Active | Zener | - | 1 | 3.3V | 4.22V | 8.8V | 22.7A | 200W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOD-123FL |
|
SMAJ5.0CATVS, BI-DIR, 400W, 5V, DO-214AC |
5,315 |
|
Datasheet | DO-214AC, SMA | SMAJx | Cut Tape (CT) | Active | Zener | - | 1 | 5V | 6.4V | 9.2V | 43.5A | 400W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | DO-214AC (SMA) |
|
|
GSMF13CATVS, BI-DIR, 200W, 13V, ESGA (SO |
5,060 |
|
Datasheet | SOD-123F | GSMF13CA | Tape & Reel (TR) | Active | Zener | - | 1 | 13V | 14.4V | 21.5V | 9.3A | 200W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOD-123FL |
|
1SMA22CAT3TVS DIODE 22VWM 35.5VC SMA |
8,519 |
|
Datasheet | DO-214AC, SMA | - | Tape & Reel (TR) | Obsolete | Zener | - | 1 | 22V | 24.4V | 35.5V | - | 400W | No | General Purpose | 280pF @ 1MHz | -65°C ~ 150°C (TJ) | - | - | Surface Mount | SMA |
|
|
SA45ARLTVS DIODE 45VWM 72.7VC AXIAL |
5,000 |
|
Datasheet | DO-204AC, DO-15, Axial | MiniMosorb™ | Bulk | Obsolete | Zener | 1 | - | 45V | 50V | 72.7V | 6.9A | 500W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Through Hole | Axial |
|
SA16ARLTRANS VOLTAGE SUPPRESSOR DIODE |
5,000 |
|
Datasheet | - | * | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
GSMF3.3ATVS, UNI-DIR, 200W, 3.3V, ESGA ( |
4,532 |
|
Datasheet | SOD-123F | - | Tape & Reel (TR) | Active | Zener | 1 | - | 3.3V | 4.22V | 8.8V | 22.7A | 200W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOD-123FL |
|
|
1SMA51CAT3GTRANS VOLTAGE SUPPRESSOR DIODE |
4,165 |
|
Datasheet | - | * | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
SA28ATVS DIODE 28VWM 45.4VC DO204AC |
4,000 |
|
Datasheet | DO-204AC, DO-15, Axial | SA | Bulk | Obsolete | Zener | 1 | - | 28V | 31.1V | 45.4V | 11.2A | 500W | No | General Purpose | - | -55°C ~ 175°C (TJ) | - | - | Through Hole | DO-204AC (DO-15) |
|
|
SA120AGTVS DIODE 120VWM 193VC AXIAL |
3,471 |
|
Datasheet | DO-204AC, DO-15, Axial | MiniMosorb™ | Bulk | Obsolete | Zener | 1 | - | 120V | 133V | 193V | 2.5A | 500W | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Through Hole | Axial |
|
CM1215-02SRTVS DIODE 4.8VC SOT143 |
5,799 |
|
Datasheet | TO-253-4, TO-253AA | - | Tape & Reel (TR) | Obsolete | Steering (Rail to Rail) | 2 | - | - | - | 4.8V (Typ) | 1A (8/20µs) | - | No | General Purpose | - | -40°C ~ 125°C (TJ) | - | - | Surface Mount | SOT-143-4 |
|
CM1215-02SOTVS DIODE 4.8VC SOT23-5 |
8,581 |
|
Datasheet | SC-74A, SOT-753 | - | Tape & Reel (TR) | Obsolete | Steering (Rail to Rail) | 2 | - | - | - | 4.8V (Typ) | 1A (8/20µs) | - | No | General Purpose | - | -40°C ~ 125°C (TJ) | - | - | Surface Mount | SOT-23-5 |
|
1SMB51CAT3TVS DIODE 51VWM 82.4VC SMB |
7,511 |
|
Datasheet | DO-214AA, SMB | - | Tape & Reel (TR) | Obsolete | Zener | - | 1 | 51V | 56.7V | 82.4V | 7.3A | 600W | No | General Purpose | 175pF @ 1MHz | -65°C ~ 150°C (TJ) | - | - | Surface Mount | SMB |
.jpg "SD36")
|
SD36TVS DIODE 36VWM 60VC SOD323 |
2,980 |
|
Datasheet | SC-76, SOD-323 | - | Cut Tape (CT) | Active | Zener | 1 | - | 36V (Max) | 40V | 75V | 5A | 350W | No | General Purpose | - | -55°C ~ 150°C (TA) | - | - | Surface Mount | SOD-323 |
|
|
SL24T1TVS LO CAP 300W 24V ESD SOT23 |
9,813 |
|
Datasheet | - | - | Tape & Reel (TR) | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
1SMB60CAT3TVS DIODE 60VWM 96.8VC SMB |
8,531 |
|
Datasheet | DO-214AA, SMB | - | Tape & Reel (TR) | Obsolete | Zener | - | 1 | 60V | 66.7V | 96.8V | 6.2A | 600W | No | General Purpose | 150pF @ 1MHz | -65°C ~ 150°C (TJ) | - | - | Surface Mount | SMB |
|
|
SRV05-4TVS DIODE 5V VBR MIN 6V SOT-23 |
1,956 |
|
Datasheet | SOT-23-6 | - | Cut Tape (CT) | Active | Steering (Rail to Rail) | 4 | - | 5V (Max) | 6V | 17.5V | 12A (8/20µs) | 300W | Yes | General Purpose | 3pF @ 1MHz | 125°C (TJ) | - | - | Surface Mount | SOT-23-6 |
Frequently Asked Questions
What are TVS Diodes components used for?
TVS Diodes components are used in a wide range of electronic equipment and systems. Their exact function depends on the device, circuit design and technical requirements of the application.
How do I choose the right TVS Diodes part?
Compare the manufacturer part number, key specifications, package type, operating conditions, availability and datasheet information. For replacement projects, always verify the critical electrical and mechanical parameters before selecting an alternative.
Can JIEXIN Electronics help source obsolete or hard-to-find TVS Diodes parts?
Yes. Send us the required manufacturer part number, quantity or BOM. Our sourcing team can help check stock availability, lead time, alternative sourcing options and quotation details.
How can I request pricing and availability?
Submit the part number, manufacturer and required quantity through our RFQ form. JIEXIN Electronics will review your request and provide available stock, pricing and sourcing information.
