TVS Diodes
Explore TVS Diodes parts from multiple manufacturers, with model information, availability, datasheets and technical specifications for engineering and purchasing.
For parts that are not shown in the list, send the manufacturer part number, quantity or BOM to JIEXIN Electronics. Our team can assist with availability checks and quotation support.
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Type | Unidirectional Channels | Bidirectional Channels | Voltage - Reverse Standoff (Typ) | Voltage - Breakdown (Min) | Voltage - Clamping (Max) @ Ipp | Current - Peak Pulse (10/1000µs) | Power - Peak Pulse | Power Line Protection | Applications | Capacitance @ Frequency | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
AK10E-380CTVS DIODE 380VWM 520VC AXIAL |
1,340 |
|
Datasheet | Axial, Right Angle Bend (24.15mm Center) | AK10E | Bulk | Active | Zener | - | 1 | 380V | 401V | 520V | 10000A (10kA) (8/20µs) | - | No | Telecom | - | -55°C ~ 125°C (TJ) | - | - | Through Hole | Axial |
|
PTVS10-320C-THTVS DIODE 320VWM 440VC AXIAL |
1,245 |
|
Datasheet | Axial, Right Angle Bend (24.15mm Center) | PTVS | Tray | Active | Zener | - | 1 | 320V (Max) | 336V | 440V (Typ) | 10000A (10kA) (8/20µs) | - | No | General Purpose | 1400pF @ 10kHz | -55°C ~ 125°C (TJ) | - | - | Through Hole | Axial |
|
AK10-380C-BPTVS DIODE 380VWM 520VC AK |
133 |
|
Datasheet | Axial, Right Angle Bend (24.15mm Center) | AK | Bulk | Active | Zener | - | 1 | 380V | 401V | 520V | 10000A (10kA) (8/20µs) | - | No | General Purpose | - | -55°C ~ 150°C (TJ) | - | - | Through Hole | AK |
|
PESD2V0Y1BHMYLPESD2V0Y1BHM/SOD962H/DSN0603-2 |
9,000 |
|
Datasheet | - | - | Tape & Reel (TR) | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
ESDZX168B-1BF4ULTRA LOW CAPACITANCE SINGLE LIN |
7,209 |
|
Datasheet | 0201 (0603 Metric) | - | Tape & Reel (TR) | Active | Zener | - | 1 | 16V (Max) | 18V | 24V | 2.2A (8/20µs) | - | No | Ethernet, HDMI, USB | 0.1pF @ 5GHz | -55°C ~ 150°C (TJ) | - | - | Surface Mount | 0201 |
|
DF2S6.8CT,L3FTVS DIODE CST2 |
9,426 |
|
Datasheet | SOD-882 | - | Tape & Reel (TR) | Active | Zener | 1 | - | - | 6.4V | - | - | - | No | General Purpose | 25pF @ 1MHz | 150°C (TJ) | - | - | Surface Mount | CST2 |
|
ESD9BL0522PESD DFN1006-2 0.5UA 5V UNIDIR |
9,020 |
|
Datasheet | SOD-882 | - | Tape & Reel (TR) | Active | Zener | - | 1 | 5V | 6V | 20V | 4A (8/20µs) | 80W | No | General Purpose | 0.4pF @ 1MHz | -50°C ~ 125°C (TJ) | - | - | Surface Mount | SOD-882 (DFN1006-2) |
|
|
ESDZV5-1BV2TVS DIODE ST0201 |
47,030 |
|
Datasheet | 01005 (0402 Metric) | - | Tape & Reel (TR) | Active | Zener | - | 1 | 5.5V | 5.8V | 7V (Typ) | 5A (8/20µs) | 45W | No | General Purpose | 5pF @ 1MHz | -40°C ~ 150°C (TJ) | - | - | Surface Mount | ST01005 |
|
ESDZV5-1BU2TVS DIODE 5.5VWM 8VC ST0201 |
18,406 |
|
Datasheet | 0201 (0603 Metric) | ESDZ | Tape & Reel (TR) | Active | Zener | - | 1 | 5.5V (Max) | 5.8V | 8V (Typ) | 7A (8/20µs) | 70W | No | General Purpose | 6pF @ 1MHz | -55°C ~ 150°C (TJ) | - | - | Surface Mount | 0201 |
|
PJSD05TM_R1_00001ESD PROTECTION DIODES |
14,650 |
|
Datasheet | SOD-923 | - | Tape & Reel (TR) | Active | Zener | 1 | - | 5V (Max) | 6.2V | 12V | 5A | 40W | No | General Purpose | 35pF @ 1MHz (Max) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOD-923 |
|
|
MMBZ33VZ-LSYLMMBZ33VZ-LS/SOD882BD/DFN1006-2 |
10,000 |
|
Datasheet | - | - | Tape & Reel (TR) | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
PESD1CANFD30L-QYLPESD1CANFD30L-Q/SOD882/DFN1006 |
10,000 |
|
Datasheet | SOD-882 | - | Tape & Reel (TR) | Active | Zener | - | 1 | 30V (Max) | 31V | 34V (Typ) | 3.9A (8/20µs) | - | No | CAN | 9.8pF @ 1MHz | -55°C ~ 150°C (TA) | Automotive | AEC-Q101 | Surface Mount | DFN1006-2 |
|
|
MMBZ27VZ-LSYLMMBZ27VZ-LS/SOD882BD/DFN1006-2 |
10,000 |
|
Datasheet | - | - | Tape & Reel (TR) | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
PESD1CANFD36L-QYLPESD1CANFD36L-Q/SOD882/DFN1006 |
9,982 |
|
Datasheet | SOD-882 | - | Tape & Reel (TR) | Active | Zener | - | 1 | 36V (Max) | 37V | 52V (Typ) | 2.9A (8/20µs) | - | No | CAN | 8.7pF @ 1MHz | -55°C ~ 150°C (TA) | Automotive | AEC-Q101 | Surface Mount | DFN1006-2 |
|
|
PESD1CANFD33L-QYLPESD1CANFD33L-Q/SOD882/DFN1006 |
9,950 |
|
Datasheet | SOD-882 | - | Tape & Reel (TR) | Active | Zener | - | 1 | 33V (Max) | 34V | 36V (Typ) | 3.8A (8/20µs) | - | No | CAN | 9.5pF @ 1MHz | -55°C ~ 150°C (TA) | Automotive | AEC-Q101 | Surface Mount | DFN1006-2 |
|
|
PESD1CANFD24L-QYLPESD1CANFD24L-Q/SOD882/DFN1006 |
9,700 |
|
Datasheet | SOD-882 | - | Tape & Reel (TR) | Active | Zener | - | 1 | 24V (Max) | 25.5V | 31V (Typ) | 3.8A (8/20µs) | - | No | CAN | 10pF @ 1MHz | -55°C ~ 150°C (TA) | Automotive | AEC-Q101 | Surface Mount | DFN1006-2 |
|
|
DF2S8.2CT,L3FTVS DIODE 6.5VWM CST2 |
9,000 |
|
Datasheet | SOD-882 | - | Tape & Reel (TR) | Active | Zener | 1 | - | 6.5V | 7.7V | - | - | - | No | General Purpose | 20pF @ 1MHz | - | - | - | Surface Mount | CST2 |
|
|
T6V0S5A-7Surge Protection PP SOD523 T&R 3 |
2,673 |
|
Datasheet | SC-79, SOD-523 | - | Bulk | Active | Zener | 1 | - | 6V | 6.8V | 20V | 13A (8/20µs) | 260W | No | General Purpose | 110pF @ 1MHz | -65°C ~ 150°C (TJ) | - | - | Surface Mount | SOD-523 |
|
P6KE6.8A-TBTVS DIODE 5.8VWM 10.5VC DO204AC |
2,000 |
|
Datasheet | DO-204AC, DO-15, Axial | P6KE | Tape & Box (TB) | Active | Zener | 1 | - | 5.8V | 6.45V | 10.5V | 58.1A | 600W | No | General Purpose | - | -55°C ~ 175°C (TJ) | - | - | Through Hole | DO-204AC (DO-15) |
;;2.jpg "P6KE6.8CA-TB")
|
P6KE6.8CA-TBTVS DIODE 5.8VWM 10.5VC DO204AC |
2,000 |
|
Datasheet | DO-204AC, DO-15, Axial | P6KE | Tape & Box (TB) | Active | Zener | - | 1 | 5.8V | 6.45V | 10.5V | 58.1A | 600W | No | General Purpose | - | -55°C ~ 175°C (TJ) | - | - | Through Hole | DO-204AC (DO-15) |
Frequently Asked Questions
What are TVS Diodes components used for?
TVS Diodes components are used in a wide range of electronic equipment and systems. Their exact function depends on the device, circuit design and technical requirements of the application.
How do I choose the right TVS Diodes part?
Compare the manufacturer part number, key specifications, package type, operating conditions, availability and datasheet information. For replacement projects, always verify the critical electrical and mechanical parameters before selecting an alternative.
Can JIEXIN Electronics help source obsolete or hard-to-find TVS Diodes parts?
Yes. Send us the required manufacturer part number, quantity or BOM. Our sourcing team can help check stock availability, lead time, alternative sourcing options and quotation details.
How can I request pricing and availability?
Submit the part number, manufacturer and required quantity through our RFQ form. JIEXIN Electronics will review your request and provide available stock, pricing and sourcing information.
