TVS Diodes
Explore TVS Diodes parts from multiple manufacturers, with model information, availability, datasheets and technical specifications for engineering and purchasing.
For parts that are not shown in the list, send the manufacturer part number, quantity or BOM to JIEXIN Electronics. Our team can assist with availability checks and quotation support.
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Type | Unidirectional Channels | Bidirectional Channels | Voltage - Reverse Standoff (Typ) | Voltage - Breakdown (Min) | Voltage - Clamping (Max) @ Ipp | Current - Peak Pulse (10/1000µs) | Power - Peak Pulse | Power Line Protection | Applications | Capacitance @ Frequency | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
TPSMA6L6.0ATVS DIODE 6VWM 10.3VC SMAF |
3,002 |
|
Datasheet | DO-221AC, SMA Flat Leads | - | Bulk | Active | Zener | 1 | - | 6V | 6.7V | 10.3V | 58.3A | 600W | No | - | - | -50°C ~ 150°C (TJ) | - | - | Surface Mount | SMAF |
|
ESD12VLHE3-TPESD PROTECTION DEVICES,DFN1006-2 |
3,460 |
|
Datasheet | 0402 (1006 Metric) | - | Tape & Reel (TR) | Active | Zener | 1 | - | 12V (Max) | 13.5V | 30V | 5A (8/20µs) | 150W | No | General Purpose | 24pF @ 1MHz | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | DFN1006-2L |
|
|
PESD5V5C1UL-QYLPESD5V5C1UL-Q/SOD882/DFN1006-2 |
6,294 |
|
Datasheet | SOD-882 | - | Tape & Reel (TR) | Active | Zener | 1 | - | 5.5V (Max) | 7V | 3.5V (Typ) | 6.5A (8/20µs) | - | No | HDMI, USB | 0.5pF @ 1MHz | -55°C ~ 150°C (TA) | Automotive | AEC-Q101 | Surface Mount | DFN1006-2 |
|
|
PUSB3CB4ZPUSB3CB4/SOT1176/XSON10 |
3,092 |
|
Datasheet | 10-XFDFN | - | Tape & Reel (TR) | Active | Steering (Rail to Rail) | - | 2 | 3.3V (Max) | 5.5V | 5.4V (Typ) | 6.5A (8/20µs) | - | Yes | HDMI, Telecom, USB | 0.19pF @ 1MHz | -40°C ~ 125°C (TA) | - | - | Surface Mount | DFN2510A-10 |
|
D12V0H1U2WSQ-7SURGE PROTECTION PP SOD323 T&R 3 |
2,577 |
|
Datasheet | SC-76, SOD-323 | - | Tape & Reel (TR) | Active | Zener | 1 | - | 12V (Max) | 13.3V | 24V | 25A (8/20µs) | 600W | No | - | 180pF @ 1MHz | -55°C ~ 125°C (TJ) | Automotive | AEC-Q101 | Surface Mount | SOD-323 |
|
CPDT-5V0UTVS DIODE 5VWM 10VC SOT23-3 |
9,611 |
|
Datasheet | TO-236-3, SC-59, SOT-23-3 | - | Tape & Reel (TR) | Active | Zener | 2 | - | 5V | 6.1V | 10V | 8A (8/20µs) | 80W | No | General Purpose | - | - | - | - | Surface Mount | SOT-23-3 |
|
|
P6SMAJ40CATVS DIODE 40VWM 64.5VC DO-214AC |
6,323 |
|
Datasheet | DO-214AC, SMA | - | Bulk | Active | Zener | - | 1 | 40V | 44.4V | 64.5V | 9.3A | 600W | No | General Purpose | - | -50°C ~ 150°C (TJ) | - | - | Surface Mount | DO-214AC (SMA) |
|
|
P6SMAJ33CATVS DIODE 33VWM 53.3VC DO-214AC |
8,784 |
|
Datasheet | DO-214AC, SMA | - | Bulk | Active | Zener | - | 1 | 33V | 36.7V | 53.3V | 11.3A | 600W | No | General Purpose | - | -50°C ~ 150°C (TJ) | - | - | Surface Mount | DO-214AC (SMA) |
|
DESD5V0XA1BCSF-7DATALINE PROTECTION PP X2-DSN060 |
6,950 |
|
Datasheet | 0201 (0603 Metric) | - | Tape & Reel (TR) | Active | Zener | - | 1 | 5V (Max) | 6V | 5.6V (Typ) | 5.5A (8/20µs) | 31W | No | General Purpose | 0.3pF @ 1MHz | -55°C ~ 150°C (TJ) | - | - | Surface Mount | X2-DSN0603-2 |
|
DESD35VF1BLP3-7DATALINE PROTECTION PP X2-DFN060 |
6,399 |
|
Datasheet | 0201 (0603 Metric) | - | Tape & Reel (TR) | Active | Zener | - | 1 | 35V (Max) | 36V | 20V | 1A (8/20µs) | - | No | General Purpose | 0.3pF @ 1MHz | -55°C ~ 150°C (TJ) | - | - | Surface Mount | X2-DFN0603-2 |
|
DESD35VF1BL-7BDATALINE PROTECTION PP X1-DFN100 |
9,144 |
|
Datasheet | 0402 (1006 Metric) | - | Tape & Reel (TR) | Active | Zener | - | 1 | 35V (Max) | 36V | 20V | 1A (8/20µs) | - | No | General Purpose | 0.3pF @ 1MHz | -65°C ~ 150°C (TJ) | - | - | Surface Mount | X1-DFN1006-2 |
|
P4SMAJ70ATVS DIODE 70VWM 113VC DO-214AC |
8,522 |
|
Datasheet | DO-214AC, SMA | - | Bulk | Active | Zener | 1 | - | 70V | 77.8V | 113V | 3.5A | 400W | No | General Purpose | - | -50°C ~ 150°C (TJ) | - | - | Surface Mount | DO-214AC (SMA) |
|
|
P4SMAJ13TVS DIODE 13VWM 23.8VC DO-214AC |
5,182 |
|
Datasheet | DO-214AC, SMA | - | Bulk | Active | Zener | 1 | - | 13V | 14.4V | 23.8V | 16.8A | 400W | No | General Purpose | - | -50°C ~ 150°C (TJ) | - | - | Surface Mount | DO-214AC (SMA) |
|
|
P4SMAJ28TVS DIODE 28VWM 50VC DO-214AC |
6,345 |
|
Datasheet | DO-214AC, SMA | - | Bulk | Active | Zener | 1 | - | 28V | 31.1V | 50V | 8A | 400W | No | General Purpose | - | -50°C ~ 150°C (TJ) | - | - | Surface Mount | DO-214AC (SMA) |
|
|
P4SMAJ7.5TVS DIODE 7.5VWM 14.3VC DO-214AC |
6,176 |
|
Datasheet | DO-214AC, SMA | - | Bulk | Active | Zener | 1 | - | 7.5V | 8.3V | 14.3V | 28A | 400W | No | General Purpose | - | -50°C ~ 150°C (TJ) | - | - | Surface Mount | DO-214AC (SMA) |
|
|
P4SMAJ14TVS DIODE 14VWM 25.8VC DO-214AC |
9,848 |
|
Datasheet | DO-214AC, SMA | - | Bulk | Active | Zener | 1 | - | 14V | 15.6V | 25.8V | 15.5A | 400W | No | General Purpose | - | -50°C ~ 150°C (TJ) | - | - | Surface Mount | DO-214AC (SMA) |
|
|
P4SMAJ36TVS DIODE 36VWM 64.3VC DO-214AC |
4,714 |
|
Datasheet | DO-214AC, SMA | - | Bulk | Active | Zener | 1 | - | 36V | 40V | 64.3V | 6.2A | 400W | No | General Purpose | - | -50°C ~ 150°C (TJ) | - | - | Surface Mount | DO-214AC (SMA) |
|
|
P4SMAJ33TVS DIODE 33VWM 59VC DO-214AC |
8,025 |
|
Datasheet | DO-214AC, SMA | - | Bulk | Active | Zener | 1 | - | 33V | 36.7V | 59V | 6.8A | 400W | No | General Purpose | - | -50°C ~ 150°C (TJ) | - | - | Surface Mount | DO-214AC (SMA) |
|
|
P4SMAJ64ATVS DIODE 64VWM 103VC DO-214AC |
7,983 |
|
Datasheet | DO-214AC, SMA | - | Bulk | Active | Zener | 1 | - | 64V | 71.1V | 103V | 3.9A | 400W | No | General Purpose | - | -50°C ~ 150°C (TJ) | - | - | Surface Mount | DO-214AC (SMA) |
|
|
P4SMAJ70TVS DIODE 70VWM 125VC DO-214AC |
5,841 |
|
Datasheet | DO-214AC, SMA | - | Bulk | Active | Zener | 1 | - | 70V | 77.8V | 125V | 3.2A | 400W | No | General Purpose | - | -50°C ~ 150°C (TJ) | - | - | Surface Mount | DO-214AC (SMA) |
Frequently Asked Questions
What are TVS Diodes components used for?
TVS Diodes components are used in a wide range of electronic equipment and systems. Their exact function depends on the device, circuit design and technical requirements of the application.
How do I choose the right TVS Diodes part?
Compare the manufacturer part number, key specifications, package type, operating conditions, availability and datasheet information. For replacement projects, always verify the critical electrical and mechanical parameters before selecting an alternative.
Can JIEXIN Electronics help source obsolete or hard-to-find TVS Diodes parts?
Yes. Send us the required manufacturer part number, quantity or BOM. Our sourcing team can help check stock availability, lead time, alternative sourcing options and quotation details.
How can I request pricing and availability?
Submit the part number, manufacturer and required quantity through our RFQ form. JIEXIN Electronics will review your request and provide available stock, pricing and sourcing information.
