Surge Protection Devices (SPDs)
Explore Surge Protection Devices (SPDs) parts from multiple manufacturers, with model information, availability, datasheets and technical specifications for engineering and purchasing.
For parts that are not shown in the list, send the manufacturer part number, quantity or BOM to JIEXIN Electronics. Our team can assist with availability checks and quotation support.
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Form | Number of Poles | Voltage - Continuous Operating (Max) (MCOV) | Current - Discharge (Nom) (8/20µS) | Current - Discharge (Max) (8/20µS) | Operating Temperature | Voltage - Protection Rating (VPR) | Voltage - Protection Level (VP) (2416) | Operating Temperature | Features | Mounting Type | Approval Agency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SPDN-B240-3DSPD TYPE 1 275V MCOV 1 POLE |
2,603 |
|
Datasheet | SPDN-B | Bulk | Active | Type 1 | Module Only | 1 | 275V | 20 kA | 130 kA | 200 kA | 1.2 kV | - | -35°C ~ 85°C | Thermally Protected, Visual Life Indicator | Panel Mount | cULus |
|
2910387SPD TYPE 1 750VAC MCOV 1 POLE |
1,846 |
|
Datasheet | VAL-US | Bulk | Active | Type 1 | Base + Module | 1 | 750VAC | 15 kA | 30 kA | 25 kA | 3.5 kV | 2.5 kV | -40°C ~ 80°C | - | DIN Rail | cUL, UL |
|
|
1260-4SMG-120SPD 150VAC MCOV 1 POLE |
3,275 |
|
Datasheet | 1260 | Box | Active | - | Base + Module | 1 | 150VAC | 25 kA | 100 kA | 50 kA | - | - | -40°C ~ 85°C | Remote Signaling Contacts, Visual Life Indicator | DIN Rail | - |
|
|
1260-4SMG-400SPD 440VAC MCOV 1 POLE |
1,833 |
|
Datasheet | 1260 | Box | Active | - | Base + Module | 1 | 440VAC | 25 kA | 100 kA | 50 kA | - | - | -40°C ~ 85°C | Remote Signaling Contacts, Visual Life Indicator | DIN Rail | - |
|
|
1260-4SMG-230SPD 275VAC MCOV 1 POLE |
2,341 |
|
Datasheet | 1260 | Box | Active | - | Base + Module | 1 | 275VAC | 25 kA | 100 kA | 50 kA | - | - | -40°C ~ 85°C | Remote Signaling Contacts, Visual Life Indicator | DIN Rail | - |
|
|
SPDN-A120-2SSPD TYPE 2 180V MCOV 1 POLE |
3,453 |
|
Datasheet | SPDN-A | Bulk | Active | Type 2 | Module Only | 1 | 180V | 20 kA | 130 kA | 200 kA | 1.2 kV | - | -40°C ~ 85°C | Thermally Protected, Visual Life Indicator | Panel Mount | cULus |
|
2910358SPD TYPE 1 264VAC MCOV 1 POLE |
2,920 |
|
Datasheet | VAL-US | Bulk | Active | Type 1 | Base + Module | 1 | 264VAC | 50 kA | - | 25 kA | 1.5 kV | 2 kV | -40°C ~ 80°C | - | DIN Rail | cUL, UL |
|
|
2591460000SPD TYPE 1/TYPE 2 300VAC MCOV |
4,064 |
|
Datasheet | - | Box | Active | Type 1, Type 2 | Base + Module | 4 | 300VAC | 50 kA | 100 kA | 150 kA | - | - | -40°C ~ 85°C | - | DIN Rail | CE, cURus, VDE |
|
|
2801160SPD TYPE 1/TYPE 2 1.17KVDC MCOV |
2,558 |
|
Datasheet | VAL-MS | Bulk | Active | Type 1, Type 2 | Base + Module | 1 | 1.17kVDC | 15 kA | 40 kA | 50 kA | 3 kV | 3.5 kV | -40°C ~ 80°C | - | DIN Rail | CB, cUR, EAC, UR |
|
|
1260-4NSMG-230SPD 275VAC MCOV 1 POLE |
1,207 |
|
Datasheet | 1260 | Box | Active | - | Base + Module | 1 | 275VAC | 25 kA | 100 kA | 50 kA | - | - | -40°C ~ 85°C | Remote Signaling Contacts, Visual Life Indicator | DIN Rail | - |
|
|
1260-4NSMG-120SPD 150VAC MCOV 1 POLE |
2,011 |
|
Datasheet | 1260 | Box | Active | - | Base + Module | 1 | 150VAC | 25 kA | 100 kA | 50 kA | - | - | -40°C ~ 85°C | Remote Signaling Contacts, Visual Life Indicator | DIN Rail | - |
|
|
2800189SPD TYPE 1/TYPE 2 335VAC MCOV |
3,601 |
|
Datasheet | VAL-MS | Bulk | Active | Type 1, Type 2 | Base + Module | 1 | 335VAC | 12.5 kA | 50 kA | 25 kA | - | 1.2 kV | -40°C ~ 80°C | - | DIN Rail | CB, cUR, cURus, EAC, UR |
|
|
2801161SPD TYPE 1/TYPE 2 1.17KVDC MCOV |
1,331 |
|
Datasheet | VAL-MS | Bulk | Active | Type 1, Type 2 | Base + Module | 1 | 1.17kVDC | 15 kA | 40 kA | 50 kA | 3 kV | 3.5 kV | -40°C ~ 80°C | - | DIN Rail | CB, cUR, cURus, EAC, UR |
|
5603514SPD 150VAC MCOV 1 POLE |
4,652 |
|
Datasheet | - | Bulk | Active | - | Module Only | 1 | 150VAC | - | 10 kA | - | - | - | -40°C ~ 85°C | - | - | - |
|
|
1260-4SMG-480SPD 600VAC MCOV 1 POLE |
1,433 |
|
Datasheet | 1260 | Box | Active | - | Base + Module | 1 | 600VAC | 25 kA | 100 kA | 50 kA | - | - | -40°C ~ 85°C | Remote Signaling Contacts, Visual Life Indicator | DIN Rail | - |
|
|
2905415SPD TYPE 1/TYPE 2 350VAC MCOV |
3,770 |
|
Datasheet | FLT | Bulk | Active | Type 1, Type 2 | Base + Module | 1 | 350VAC | 25 kA | 50 kA | 50 kA | 1.5 kV | 2.5 kV | -40°C ~ 80°C | - | DIN Rail | CB, cUR, cURus, EAC, UR |
|
|
SPDN-A120-3YSPD TYPE 2 150V MCOV 1 POLE |
2,850 |
|
Datasheet | SPDN-A | Bulk | Active | Type 2 | Module Only | 1 | 150V | 20 kA | 130 kA | 200 kA | 1.2 kV | - | -40°C ~ 85°C | Thermally Protected, Visual Life Indicator | Panel Mount | cULus |
|
|
SPDN-A240-3DSPD TYPE 2 275V MCOV 1 POLE |
4,460 |
|
Datasheet | SPDN-A | Bulk | Active | Type 2 | Module Only | 1 | 275V | 20 kA | 130 kA | 200 kA | 1.2 kV | - | -40°C ~ 85°C | Thermally Protected, Visual Life Indicator | Panel Mount | cULus |
|
|
SPDN-A480-3DSPD TYPE 2 550V MCOV 1 POLE |
2,938 |
|
Datasheet | SPDN-A | Bulk | Active | Type 2 | Module Only | 1 | 550V | 20 kA | 130 kA | 200 kA | 1.8 kV | - | -40°C ~ 85°C | Thermally Protected, Visual Life Indicator | Panel Mount | cULus |
|
|
SPDN-A277-3YSPD TYPE 2 350V MCOV 1 POLE |
4,312 |
|
Datasheet | SPDN-A | Bulk | Active | Type 2 | Module Only | 1 | 350V | 20 kA | 130 kA | 200 kA | 2.5 kV | - | -40°C ~ 85°C | Thermally Protected, Visual Life Indicator | Panel Mount | cULus |
Frequently Asked Questions
What are Surge Protection Devices (SPDs) components used for?
Surge Protection Devices (SPDs) components are used in a wide range of electronic equipment and systems. Their exact function depends on the device, circuit design and technical requirements of the application.
How do I choose the right Surge Protection Devices (SPDs) part?
Compare the manufacturer part number, key specifications, package type, operating conditions, availability and datasheet information. For replacement projects, always verify the critical electrical and mechanical parameters before selecting an alternative.
Can JIEXIN Electronics help source obsolete or hard-to-find Surge Protection Devices (SPDs) parts?
Yes. Send us the required manufacturer part number, quantity or BOM. Our sourcing team can help check stock availability, lead time, alternative sourcing options and quotation details.
How can I request pricing and availability?
Submit the part number, manufacturer and required quantity through our RFQ form. JIEXIN Electronics will review your request and provide available stock, pricing and sourcing information.
