RF Antennas
Review RF Antennas RF and Wireless components in this filtered selection. Compare manufacturer information, availability, pricing, datasheets and key specifications to narrow down suitable parts for your application.
If the exact part or specification you need is not listed, send the manufacturer part number, target parameters and quantity to JIEXIN Electronics for sourcing and quotation support.
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | RF Family/Standard | Frequency Group | Frequency (Center/Band) | Frequency Range | Antenna Type | Number of Bands | VSWR | Return Loss | Gain | Power - Max | Features | Termination | Ingress Protection | Grade | Qualification | Mounting Type | Height (Max) | Applications |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
RAZ32012MMRF ANT 802MHZ/1.582GHZ MOD MAGNT |
2,292 |
|
Datasheet | RAZORBACK | Bulk | Active | Cellular, Navigation | Wide Band | 802MHz, 1.582GHz, 2.2GHz | 644MHz ~ 960MHz, 1.559GHz ~ 1.606GHz, 1.71GHz ~ 2.69GHz | Module | 3 | 2 | - | 4.6dBi, 4.9dBi, 6dBi, 6.6dBi | 45 W | Cable - 5.18m, LNA | SMA Male (3) | IP67 | - | - | Magnetic | 3.727" (94.67mm) | GPS, LTE |
|
ARM62311DMRF ANT 829MHZ/1.582GHZ MOD PANEL |
3,977 |
|
Datasheet | ARMADILLO | Bulk | Active | Cellular, Navigation, WiFi | Wide Band | 829MHz, 1.582GHz, 2.2GHz, 2.45GHz, 5.537GHz | 698MHz ~ 960MHz, 1.559GHz ~ 1.606GHz, 1.71GHz ~ 2.69GHz, 2.4GHz ~ 2.5GHz, 5.15GHz ~ 5.925GHz | Module | 6 | 2, 2.5 | - | 4.9dBi, 5.3dBi, 4.6dBi, 6.6dBi | - | Cable - 5.18m, LNA | SMA Male (3), RP-SMA Male (3) | IP67 | - | - | Panel Mount | 1.772" (45.00mm) | GPS, LTE, Wi-Fi |
|
ARM5G62312DMANT VHCL MULTIBAND W/DIRECT WHT |
2,840 |
|
Datasheet | ARMADILLO | Bag | Active | Cellular, Navigation, WiFi | Wide Band | 788.5MHz, 1.561GHz, 1.575GHz, 1.602GHz, 2.45GHz, 3.855GHz, 5.537GHz | 617MHz, 1.559GHz, 1.574GHz, 1.598GHz, 1.71GHz, 2.4GHz, 5.15GHz | Module | 7 | 2, 2.2, 2.5 | - | 2.2dBi, 5.4dBi, 4.6dBi, 6.3dBi | - | Cable - 5.18M, LNA | RP-SMA Male (3), SMA Male (3) | IP67 | - | - | Surface Mount | 1.772" (45.00mm) | 4G, 5G, BeiDou, GLONASS, GNSS, GPS, LTE |
|
GPSMB401RF ANT MODULE RP-SMA MALE PAN MT |
3,180 |
|
Datasheet | - | Bag | Active | Cellular, Navigation, WiFi | Wide Band | - | - | Module | 6 | 1.5 | - | 5dBi | - | LNA, Filter | RP-SMA Male, SMA Male | IP67 | - | - | Panel Mount | 2.992" (76.00mm) | GPS, LTE, Wi-Fi |
|
ANT1204LL16R0870ARF ANT 870MHZ CHIP SOLDER SMD |
1,000 |
|
Datasheet | 1204 | Tape & Reel (TR) | Active | General ISM | UHF (300MHz ~ 1GHz) | 870MHz | - | Chip | 1 | - | 6.49dB | 1.05dBi | 1 W | - | Solder | - | - | - | Surface Mount | 0.047" (1.20mm) | ISM |
|
W3333RF ANT 895MHZ/2.4GHZ PCB TRACE |
324 |
|
Datasheet | - | Bulk | Active | 802.15.4, Bluetooth, WiFi | UHF (300MHz ~ 1GHz), UHF (2GHz ~ 3GHz) | 895MHz, 2.4GHz | 863MHz ~ 928MHz, 2.4GHz ~ 2.5GHz | PCB Trace | 2 | - | -15dB | 4dBi | 3 W | - | Solder | - | - | - | Surface Mount | 0.031" (0.80mm) | Bluetooth, WLAN, Zigbee™ |
|
|
W6108B0100ANT MIMO WIFI 6E FPC 100MM 4X4 |
1,269 |
|
Datasheet | - | Bag | Active | WiFi | Wide Band | 2.44GHz, 6.15GHz | 2.4GHz ~ 2.48GHz, 5.15GHz ~ 7.15GHz | Flat Patch | 2 | - | 7dB | 3.7dBi, 7.4dBi | 1 W | Cable - 100mm | U.FL | - | - | - | Adhesive | - | Wi-Fi |
|
GPSMOD2533RF ANT 1.575GHZ CER PATCH SLD |
2,932 |
|
Datasheet | - | Bulk | Active | Navigation | UHF (1GHz ~ 2GHz) | 1.575GHz | - | Ceramic Patch | 1 | 1.5 | - | 1dB | - | LNA | Solder | - | - | - | Surface Mount | - | GPS |
|
|
BT25B0150ANTENNA 2.4GHZ PATCH I-PEX MHF |
1,191 |
|
Datasheet | - | Box | Active | Bluetooth, General ISM, WiFi | UHF (2GHz ~ 3GHz) | 2.45GHz | 2.4GHz ~ 2.5GHz | Ceramic Patch | 1 | - | -6dB | 3.5dBic | - | Cable - 150.114mm | I-PEX MHF | - | - | - | Adhesive | 0.260" (6.60mm) | Bluetooth, ISM, Wi-Fi |
|
|
SB617-7125G0400STEALTH BLADE |
100 |
|
Datasheet | - | Bag | Active | Cellular, Navigation | Wide Band | 788.5MHz, 2.205GHz, 3.75GHz, 4.7GHz, 6.137GHz | 617MHz ~ 960MHz, 1.71GHz ~ 2.7GHz, 3.3GHz ~ 4.2GHz, 4.4GHz ~ 5GHz, 5.15GHz ~ 7.125GHz | Flat Bar | 5 | - | -6dB | 3.5dBi, 5.5dBi, 6.5dBi, 5.2dBi, 3dBi | 3 W | Cable - 400mm | SMA Male | IP67 | - | - | Connector Mount | 0.080" (2.03mm) | 4G, 5G, IoT, LTE, Wi-Fi |
Frequently Asked Questions
What are RF Antennas components used for?
RF Antennas components are used in a wide range of electronic equipment and systems. Their exact function depends on the device, circuit design and technical requirements of the application.
How do I choose the right RF Antennas part?
Compare the manufacturer part number, key specifications, package type, operating conditions, availability and datasheet information. For replacement projects, always verify the critical electrical and mechanical parameters before selecting an alternative.
Can JIEXIN Electronics help source obsolete or hard-to-find RF Antennas parts?
Yes. Send us the required manufacturer part number, quantity or BOM. Our sourcing team can help check stock availability, lead time, alternative sourcing options and quotation details.
How can I request pricing and availability?
Submit the part number, manufacturer and required quantity through our RFQ form. JIEXIN Electronics will review your request and provide available stock, pricing and sourcing information.
