Power Transformers
Review Power Transformers Transformers components in this filtered selection. Compare manufacturer information, availability, pricing, datasheets and key specifications to narrow down suitable parts for your application.
If the exact part or specification you need is not listed, send the manufacturer part number, target parameters and quantity to JIEXIN Electronics for sourcing and quotation support.
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Type | Voltage - Primary | Voltage - Secondary (Full Load) | Current - Output (Max) | Primary Winding(s) | Secondary Winding(s) | Center Tap | Power - Max | Mounting Type | Termination Style | Size / Dimension | Height - Seated (Max) | Voltage - Isolation | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
241-8-56LPWR XFMR LAMINATED 100VA CHAS MT |
4,967 |
|
Datasheet | Two-4-One™ | Bulk | Active | Laminated Core | 115V | 56V | 1.8A | Single | Single | Yes | 100VA | Chassis Mount | Wire Leads | 102.40mm L x 58.50mm W | 67.70mm | 2500Vrms | 2.8 lbs (1.3 kg) |
|
IF-24-230PWR XFMR SEMI-TORO 24VA TH |
2,496 |
|
Datasheet | IF | Bulk | Active | Semi-Toroidal | 115V, 230V | Parallel 115V, Series 230V | Parallel 210mA, Series 105mA | Dual | Dual | No | 24VA | Through Hole | PC Pin | 68.00mm L x 57.50mm W | 31.30mm | 4000Vrms | 1.03 lbs (467.2 g) |
|
DP-241-8-10LPWR XFMR LAMINATED 100VA CHAS MT |
2,559 |
|
Datasheet | Two-4-One™ | Bulk | Active | Laminated Core | 115V, 230V | 10V | 10A | Dual | Single | Yes | 100VA | Chassis Mount | Wire Leads | 102.40mm L x 58.50mm W | 67.70mm | 2500Vrms | 2.8 lbs (1.3 kg) |
|
A41-80-512PWR XFMR LAMINATED 80VA CHAS MT |
4,995 |
|
Datasheet | All-4-One™ | Bulk | Active | Laminated Core | 115V, 230V | Parallel 5V, Series 12V | Parallel 3.5A, Series 600mA | Dual | Dual | Yes | 80VA | Chassis Mount | Solder, Quick Connect | 63.50mm L x 64.30mm W | 76.20mm | 4000Vrms | 2.8 lbs (1.3 kg) |
|
DMT-8-15PWR XFMR LAMINATED 8VA CHAS MT |
2,519 |
|
Datasheet | DMT | Bulk | Active | Laminated Core | 115V, 230V | 5V, 15V | 4A, 500mA | Dual | Dual | Yes | 8VA | Chassis Mount | Solder, Quick Connect | 102.40mm L x 58.50mm W | 67.70mm | 2500Vrms | 2.8 lbs (1.3 kg) |
|
24-1PWR XFMR LAMINATED 24VA CHAS MT |
1,709 |
|
Datasheet | - | Box | Active | Laminated Core | 105V, 115V, 125V | Parallel 12V, Series 24V | Parallel 2A, Series 1A | Single, Multiple Taps | Dual | Yes | 24VA | Chassis Mount | Solder, Quick Connect | 76.20mm L x 63.50mm W | 63.50mm | 1500Vrms | 2.3 lbs (1 kg) |
|
A41-175-16PWR XFMR LAMINATED 175VA CHAS MT |
1,912 |
|
Datasheet | All-4-One™ | Box | Active | Laminated Core | 115V, 230V | Parallel 8V, Series 16V | Parallel 22A, Series 11A | Dual | Dual | No | 175VA | Chassis Mount | Solder, Quick Connect | 79.40mm L x 79.70mm W | 95.30mm | 4000Vrms | 5.5 lbs (2.5 kg) |
-Series.jpg "A41-175-230L")
|
A41-175-230LPWR XFMR LAMINATED 175VA CHAS MT |
1,961 |
|
Datasheet | All-4-One™ | Box | Active | Laminated Core | 115V, 230V | Parallel 115V, Series 230V | Parallel 1.52A, Series 760mA | Dual | Dual | No | 175VA | Chassis Mount | Wire Leads | 79.40mm L x 79.70mm W | 95.30mm | 4000Vrms | 5.5 lbs (2.5 kg) |
|
|
A41-175-12PWR XFMR LAMINATED 175VA CHAS MT |
4,754 |
|
Datasheet | All-4-One™ | Box | Active | Laminated Core | 115V, 230V | Parallel 6.3V, Series 12.6V | Parallel 28A, Series 14A | Dual | Dual | No | 175VA | Chassis Mount | Solder, Quick Connect | 79.40mm L x 79.70mm W | 95.30mm | 4000Vrms | 5.5 lbs (2.5 kg) |
|
56-1PWR XFMR LAMINATED 56VA CHAS MT |
4,888 |
|
Datasheet | - | Box | Active | Laminated Core | 105V, 115V, 125V | Parallel 28V, Series 56V | Parallel 2A, Series 1A | Single, Multiple Taps | Dual | Yes | 56VA | Chassis Mount | Solder, Quick Connect | 85.70mm L x 73.00mm W | 71.40mm | 1500Vrms | 3.5 lbs (1.6 kg) |
Frequently Asked Questions
What are Power Transformers components used for?
Power Transformers components are used in a wide range of electronic equipment and systems. Their exact function depends on the device, circuit design and technical requirements of the application.
How do I choose the right Power Transformers part?
Compare the manufacturer part number, key specifications, package type, operating conditions, availability and datasheet information. For replacement projects, always verify the critical electrical and mechanical parameters before selecting an alternative.
Can JIEXIN Electronics help source obsolete or hard-to-find Power Transformers parts?
Yes. Send us the required manufacturer part number, quantity or BOM. Our sourcing team can help check stock availability, lead time, alternative sourcing options and quotation details.
How can I request pricing and availability?
Submit the part number, manufacturer and required quantity through our RFQ form. JIEXIN Electronics will review your request and provide available stock, pricing and sourcing information.
