Power Relays, Over 2 Amps
Explore Power Relays, Over 2 Amps parts from multiple manufacturers, with model information, availability, datasheets and technical specifications for engineering and purchasing.
For parts that are not shown in the list, send the manufacturer part number, quantity or BOM to JIEXIN Electronics. Our team can assist with availability checks and quotation support.
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Mounting Type | Coil Voltage | Contact Form | Contact Rating (Current) | Switching Voltage | Load - Max Switching | Coil Current | Coil Type | Features | Termination Style | Seal Rating | Coil Insulation | Must Operate Voltage | Must Release Voltage | Operate Time | Release Time | Operating Temperature | Contact Material | Relay Type | Grade | Qualification |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MJN2CK-DC24RELAY GEN PURPOSE DPDT 10A 24V |
382 |
|
Datasheet | MJN | Bulk | Active | Socketable | 24VDC | DPDT (2 Form C) | 10 A | 600VAC, 28VDC - Max | 6000VA, 280W | 50 mA | Latching, Single Coil | - | Plug In, Quick Connect - 0.187" (4.7mm) | - | - | 18 VDC | - | 20 ms | 10 ms | -45°C ~ 70°C | Silver Alloy | General Purpose | - | - |
|
G9KB-1A DC12RELAY GEN PURPOSE SPST 50A 12V |
127 |
|
Datasheet | G9KB | Tray | Active | Through Hole | 12VDC | SPST-NO (1 Form A) | 50 A | 600VDC - Max | 30000W | 235.3 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | Class F | 9 VDC | 1.2 VDC | 30 ms | 10 ms | -40°C ~ 85°C | Silver Alloy, Cadmium Free | General Purpose | - | - |
|
KUEP-3D15-125RELAY GEN PURPOSE SPST 10A 125V |
202 |
|
Datasheet | KUEP | Bulk | Active | Socketable | 125VDC | SPST-NO (DM) (1 Form X) | 10 A | 150VDC - Max | 1500VA | 9.6 mA | Non Latching | - | Plug In, Quick Connect - 0.187" (4.7mm) | - | Class B | 93.75 VDC | - | 15 ms | 10 ms | -45°C ~ 70°C | Silver Cadmium Oxide (AgCdO) | General Purpose | - | - |
|
1148703RELAY GEN PURPOSE 4PST 6A 24V |
4,435 |
|
Datasheet | RIF | Box | Active | DIN Rail | 24VDC | 4PST-3NO/1NC (3 Form A, 1 Form B) | 6 A | 250VAC, 300VDC - Max | 1500VA, 240W | 17 mA | Non Latching | Diode, Lighted Indicator, Socket Included | Spring Terminal | - | - | - | - | 10 ms | 15 ms | -40°C ~ 60°C | Silver Tin Oxide (AgSnO), Gold (Au) | General Purpose | - | - |
|
2901639RELAY GEN PURPOSE SPST 3.5A 24V |
4,040 |
|
Datasheet | PLC-RPT | Bulk | Active | DIN Rail | 24VDC | SPST-NO (1 Form A) x 2 | 3.5 A | 250VAC, 30VDC - Max | 875VA, 105W | 7 mA | Non Latching | Diode, Lighted Indicator, Socket Included | Spring Terminal | - | - | - | - | 4 ms | 6 ms | -20°C ~ 60°C | Silver Nickel (AgNi) | General Purpose | - | - |
|
AEP52024RELAY GEN PURPOSE SPST 20A 24V |
1,892 |
|
Datasheet | AEP | Box | Active | Chassis Mount | 24VDC | SPST-NO (1 Form A) | 20 A | 277VAC, 400VDC - Nom | 5540VA | 163 mA | Non Latching | - | Quick Connect - 0.187" (4.7mm) | Sealed - Hermetically | - | 18 VDC | 1 VDC | 50 ms | 30 ms | -40°C ~ 80°C | - | General Purpose | - | - |
|
G7L-2A-X-SI DC12RELAY GEN PURPOSE DPST 30A 12V |
185 |
|
Datasheet | G7L-X | Tray | Active | Through Hole | 12VDC | DPST-NO (2 Form A) | 30 A | 1000VDC - Max | 25000W | 191.7 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | Class F | 9 VDC | 1.2 VDC | 30 ms | 30 ms | -40°C ~ 85°C | Silver Alloy, Cadmium Free | General Purpose | - | - |
|
PRD-11DG0-12RELAY GEN PURPOSE DPDT 30A 12V |
4,754 |
|
Datasheet | PRD | Bulk | Active | Chassis Mount | 12VDC | DPDT (2 Form C) | 30 A | 600VAC, 125VDC - Nom | - | 169 mA | Non Latching | - | Screw Terminal | - | Class B | 9 VDC | 1.2 VDC | 40 ms | 20 ms | -55°C ~ 80°C | Silver Cadmium Oxide (AgCdO) | General Purpose | - | - |
|
KRPA-11DG-125RELAY GEN PURPOSE DPDT 10A 125V |
3,048 |
|
Datasheet | KRPA | Tray | Active | Socketable | 125VDC | DPDT (2 Form C) | 10 A | 240VAC - Max | 2400VA | 9.6 mA | Non Latching | - | Plug In, 8 Pin (Octal) | - | Class B | 93.75 VDC | - | - | - | -45°C ~ 70°C | Silver Cadmium Oxide (AgCdO) | General Purpose | - | - |
|
788-384RELAY GEN PURPOSE DPDT 6A 24V |
189 |
|
Datasheet | 788 | Bulk | Active | DIN Rail | 24VDC | DPDT (2 Form C) | 6 A | 250VAC - Max | 1500VA | 31 mA | Non Latching | Lighted Indicator | Spring Terminal | - | - | 20.4 VDC | - | 10 ms | 4 ms | -40°C ~ 70°C | Silver Nickel (AgNi) | General Purpose | - | - |
|
G7L-2A-X-L DC12RELAY GEN PURPOSE DPST 20A 12V |
774 |
|
Datasheet | G7L-X | Tray | Active | Through Hole | 12VDC | DPST-NO (2 Form A) | 20 A | 1000VDC - Max | 20000W | 192 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | Class F | 9 VDC | 1.2 VDC | 30 ms | 30 ms | -40°C ~ 85°C | Silver Alloy, Cadmium Free | General Purpose | - | - |
|
2941154RELAY GEN PURPOSE SPST 3A 24V |
390 |
|
Datasheet | - | Bulk | Active | DIN Rail | 24VAC/DC | SPST-NO (1 Form A) | 3 A | 250VAC, 250VDC - Max | - | 6.5 mA | Non Latching | - | Screw Terminal | - | - | - | - | 5 ms | 15 ms | -20°C ~ 50°C | Silver Nickel (AgNi) | General Purpose | - | - |
|
2964500RELAY GEN PURPOSE SPDT 6A 24V |
2,843 |
|
Datasheet | - | Bulk | Active | DIN Rail | 24VDC | SPDT (1 Form C) | 6 A | 250VAC, 250VDC - Max | - | 9 mA | Non Latching | - | Screw Terminal | - | - | - | - | 8 ms | 5 ms | -20°C ~ 50°C | Silver Tin Oxide (AgSnO) | General Purpose | - | - |
|
R10-E1X6-V430RELAY GEN PURPOSE 6PDT 5A 24V |
198 |
|
Datasheet | R10 | Bulk | Active | Socketable | 24VDC | 6PDT (6 Form C) | 5 A | 120VAC - Nom | - | 55.8 mA | Non Latching | - | Plug In | - | - | 18 VDC | - | - | - | -55°C ~ 75°C | Silver Cadmium Oxide (AgCdO) | General Purpose | - | - |
|
PRD-11AH0-120RELAY GEN PURPOSE DPDT 20A 120V |
4,100 |
|
Datasheet | PRD | Bulk | Active | Chassis Mount | 120VAC | DPDT (2 Form C) | 20 A | 600VAC, 125VDC - Nom | - | 85 mA | Non Latching | - | Screw Terminal | - | Class B | 102 VAC | 12 VAC | 40 ms | 20 ms | -55°C ~ 45°C | Silver (Ag) | General Purpose | - | - |
|
HEV2AN-P-DC12VRELAY GEN PURPOSE DPST 20A 12V |
101 |
|
Datasheet | HE-V | Tray | Active | Through Hole | 12VDC | DPST-NO (2 Form A) | 20 A | 1000VDC - Max | 20000W | 160 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | Class F | 8.4 VDC | 0.6 VDC | 30 ms | 10 ms | -40°C ~ 55°C | Silver Nickel (AgNi) | General Purpose | - | - |
|
KUL-11A15S-120RELAY GEN PURPOSE DPDT 10A 120V |
100 |
|
Datasheet | KUL | Bulk | Active | Socketable | 120VAC | DPDT (2 Form C) | 10 A | 240VAC - Max | 2400VA | 32.4 mA | Latching, Single Coil | - | Plug In, Quick Connect - 0.187" (4.7mm) | - | Class B | 102 VAC | - | 25 ms | 25 ms | -45°C ~ 70°C | Silver Cadmium Oxide (AgCdO) | General Purpose | - | - |
|
|
G9KA-1A-E DC24RELAY GEN PURPOSE SPST 300A 24V |
360 |
|
Datasheet | G9KA | Tray | Active | Through Hole | 24VDC | SPST-NO (1 Form A) | 300 A | 1000VAC - Max | 300000VA | 208 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | Class F | 18 VDC | 1.2 VDC | 30 ms | 10 ms | -40°C ~ 85°C | Silver Alloy, Cadmium Free | General Purpose | - | - |
|
|
G7L-2A-X DC24RELAY GEN PURPOSE DPST 25A 24V |
197 |
|
Datasheet | G7L-X | Tray | Active | Through Hole | 24VDC | DPST-NO (2 Form A) | 30 A | 1000VDC - Max | 25000W | 95.8 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | Class F | 18 VDC | 2.4 VDC | 30 ms | 30 ms | -40°C ~ 85°C | Silver Alloy, Cadmium Free | General Purpose | - | - |
|
|
G7L-2A-X DC12RELAY GEN PURPOSE DPST 25A 12V |
245 |
|
Datasheet | G7L-X | Tray | Active | Through Hole | 12VDC | DPST-NO (2 Form A) | 30 A | 1000VDC - Max | 25000W | 192 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | Class F | 9 VDC | 1.2 VDC | 30 ms | 30 ms | -40°C ~ 85°C | Silver Alloy, Cadmium Free | General Purpose | - | - |
Frequently Asked Questions
What are Power Relays, Over 2 Amps components used for?
Power Relays, Over 2 Amps components are used in a wide range of electronic equipment and systems. Their exact function depends on the device, circuit design and technical requirements of the application.
How do I choose the right Power Relays, Over 2 Amps part?
Compare the manufacturer part number, key specifications, package type, operating conditions, availability and datasheet information. For replacement projects, always verify the critical electrical and mechanical parameters before selecting an alternative.
Can JIEXIN Electronics help source obsolete or hard-to-find Power Relays, Over 2 Amps parts?
Yes. Send us the required manufacturer part number, quantity or BOM. Our sourcing team can help check stock availability, lead time, alternative sourcing options and quotation details.
How can I request pricing and availability?
Submit the part number, manufacturer and required quantity through our RFQ form. JIEXIN Electronics will review your request and provide available stock, pricing and sourcing information.
