Oscillators
Review Oscillators Crystals, Oscillators, Resonators components in this filtered selection. Compare manufacturer information, availability, pricing, datasheets and key specifications to narrow down suitable parts for your application.
If the exact part or specification you need is not listed, send the manufacturer part number, target parameters and quantity to JIEXIN Electronics for sourcing and quotation support.
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Base Resonator | Type | Frequency | Function | Output | Voltage - Supply | Frequency Stability | Absolute Pull Range (APR) | Operating Temperature | Spread Spectrum Bandwidth | Current - Supply (Max) | Ratings | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
TG-5006CE-16H 16.3680M6TG-5006CE-16H 16.3680M6: TCXO 1. |
2,945 |
|
Datasheet | TG-5006CE | 4-SMD, No Lead | Tape & Reel (TR) | Active | Crystal | TCXO | 16.368 MHz | - | Clipped Sine Wave | 1.7V ~ 3.465V | ±2ppm | - | -30°C ~ 85°C | - | 1.5mA | - | Surface Mount | 4-VDFN (3.2x2.5) | 0.126" L x 0.098" W (3.20mm x 2.50mm) | 0.039" (1.00mm) |
|
|
TG-5006CE-19H 26.0000M6TG-5006CE-19H 26.0000M6: TCXO MH |
3,790 |
|
Datasheet | TG-5006CE | 4-SMD, No Lead | Tape & Reel (TR) | Active | Crystal | TCXO | 26 MHz | - | Clipped Sine Wave | 1.7V ~ 3.465V | ±2ppm | - | -30°C ~ 85°C | - | 1.5mA | - | Surface Mount | 4-VDFN (3.2x2.5) | 0.126" L x 0.098" W (3.20mm x 2.50mm) | 0.039" (1.00mm) |
|
|
TG-5006CE-44W 19.2000M6TG-5006CE-44W 19.2000M6: TCXO 2K |
8,118 |
|
Datasheet | TG-5006CE | 4-SMD, No Lead | Tape & Reel (TR) | Active | Crystal | TCXO | 19.2 MHz | - | Clipped Sine Wave | 1.7V ~ 3.465V | ±2ppm | - | -30°C ~ 85°C | - | 1.5mA | - | Surface Mount | 4-VDFN (3.2x2.5) | 0.126" L x 0.098" W (3.20mm x 2.50mm) | 0.039" (1.00mm) |
|
|
TG-5006CE-53W 40.0000M0TG-5006CE-53W 40.0000M0: VC-TCXO |
3,220 |
|
Datasheet | TG-5006CE | 4-SMD, No Lead | Tape & Reel (TR) | Active | Crystal | VCTCXO | 40 MHz | - | Clipped Sine Wave | 1.7V ~ 3.465V | ±2ppm | - | -30°C ~ 85°C | - | 2mA | - | Surface Mount | 4-VDFN (3.2x2.5) | 0.126" L x 0.098" W (3.20mm x 2.50mm) | 0.039" (1.00mm) |
|
|
SG-9101CG 64.0000M-C20PHAAA0SG-9101CG 64.0000M-C20PHAAA0: MH |
3,748 |
|
Datasheet | - | - | Tape & Reel (TR) | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
SG-210SGB 25.0000ML5XTAL OSC XO 25.0000MHZ CMOS SMD |
2,384 |
|
Datasheet | SG-210SGB | 4-SMD, No Lead | Tape & Reel (TR) | Obsolete | Crystal | XO (Standard) | 25 MHz | Standby (Power Down) | CMOS | 1.5V | ±50ppm | - | -40°C ~ 85°C | - | 1mA | - | Surface Mount | 4-VDFN (3.2x2.5) | 0.098" L x 0.079" W (2.50mm x 2.00mm) | 0.035" (0.90mm) |
.JPG "SG-3030CM 32.7680KB3: ROHS")
|
SG-3030CM 32.7680KB3: ROHSXTAL OSC XO 32.7680KHZ CMOS SMD |
3,539 |
|
Datasheet | SG-3030 | 4-SMD, No Lead | Tape & Reel (TR) | Obsolete | Crystal | XO (Standard) | 32.768 kHz | - | CMOS | 1.5V ~ 5.5V | - | - | -20°C ~ 70°C | - | 2µA | - | Surface Mount | 4-SMD (3.2x1.5) | 0.126" L x 0.059" W (3.20mm x 1.50mm) | 0.035" (0.90mm) |
|
SG-636PCE 2.4576MC0:ROHSXTAL OSC XO 2.4576MHZ CMOS SMD |
7,244 |
|
Datasheet | SG-636 | 4-SOJ, 5.08mm pitch | Tape & Reel (TR) | Obsolete | Crystal | XO (Standard) | 2.4576 MHz | Enable/Disable | CMOS | 3.3V | ±100ppm | - | -20°C ~ 70°C | - | 9mA | - | Surface Mount | 4-SOJ | 0.413" L x 0.197" W (10.50mm x 5.00mm) | 0.106" (2.70mm) |
|
|
SG-636PCE 3.6864MC0:ROHSXTAL OSC XO 3.6864MHZ CMOS SMD |
4,129 |
|
Datasheet | SG-636 | 4-SOJ, 5.08mm pitch | Tape & Reel (TR) | Obsolete | Crystal | XO (Standard) | 3.6864 MHz | Enable/Disable | CMOS | 3.3V | ±100ppm | - | -20°C ~ 70°C | - | 9mA | - | Surface Mount | 4-SOJ | 0.413" L x 0.197" W (10.50mm x 5.00mm) | 0.106" (2.70mm) |
|
|
SG-636PCE 4.0000MC0:ROHSXTAL OSC XO 4.0000MHZ CMOS SMD |
4,915 |
|
Datasheet | SG-636 | 4-SOJ, 5.08mm pitch | Tape & Reel (TR) | Obsolete | Crystal | XO (Standard) | 4 MHz | Enable/Disable | CMOS | 3.3V | ±100ppm | - | -20°C ~ 70°C | - | 9mA | - | Surface Mount | 4-SOJ | 0.413" L x 0.197" W (10.50mm x 5.00mm) | 0.106" (2.70mm) |
Frequently Asked Questions
What are Oscillators components used for?
Oscillators components are used in a wide range of electronic equipment and systems. Their exact function depends on the device, circuit design and technical requirements of the application.
How do I choose the right Oscillators part?
Compare the manufacturer part number, key specifications, package type, operating conditions, availability and datasheet information. For replacement projects, always verify the critical electrical and mechanical parameters before selecting an alternative.
Can JIEXIN Electronics help source obsolete or hard-to-find Oscillators parts?
Yes. Send us the required manufacturer part number, quantity or BOM. Our sourcing team can help check stock availability, lead time, alternative sourcing options and quotation details.
How can I request pricing and availability?
Submit the part number, manufacturer and required quantity through our RFQ form. JIEXIN Electronics will review your request and provide available stock, pricing and sourcing information.
