Fixed Inductors
Explore Fixed Inductors parts from multiple manufacturers, with model information, availability, datasheets and technical specifications for engineering and purchasing.
For parts that are not shown in the list, send the manufacturer part number, quantity or BOM to JIEXIN Electronics. Our team can assist with availability checks and quotation support.
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CTHCCI1210F-4R7MSMD SHIELDED POWER INDUCTOR |
2,542 |
|
Datasheet | CTHCCI1210F | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 4.7 µH | ±20% | 12 A | 11A | Shielded | 8.8mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.524" L x 0.461" W (13.30mm x 11.70mm) | 0.394" (10.00mm) |
|
|
CTHCCI1210F-1R0MSMD SHIELDED POWER INDUCTOR |
2,950 |
|
Datasheet | CTHCCI1210F | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 1 µH | ±20% | 30 A | 28A | Shielded | 2.4mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.524" L x 0.461" W (13.30mm x 11.70mm) | 0.394" (10.00mm) |
|
|
CTHCCI1210F-2R2MSMD SHIELDED POWER INDUCTOR |
2,125 |
|
Datasheet | CTHCCI1210F | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 2.2 µH | ±20% | 21 A | 18A | Shielded | 4.7mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.524" L x 0.461" W (13.30mm x 11.70mm) | 0.394" (10.00mm) |
|
CTHCCI1090F-1R0MSMD SHLDED POWER INDUCTOR |
4,777 |
|
Datasheet | CTHCCI1090F | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 1 µH | ±20% | 17 A | 21A | Shielded | 2.65mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.445" L x 0.409" W (11.30mm x 10.40mm) | 0.382" (9.70mm) |
|
|
CTHCCI1090F-3R3MSMD SHIELDED POWER INDUCTOR |
4,510 |
|
Datasheet | CTHCCI1090F | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 3.3 µH | ±20% | 11 A | 10A | Shielded | 7.7mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.445" L x 0.409" W (11.30mm x 10.40mm) | 0.382" (9.70mm) |
|
|
CTHCCI1210F-R47MSMD SHIELDED POWER INDUCTOR |
3,219 |
|
Datasheet | CTHCCI1210F | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 470 nH | ±20% | 35 A | 45A | Shielded | 1.8mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.524" L x 0.461" W (13.30mm x 11.70mm) | 0.394" (10.00mm) |
|
|
CTHCCI1090F-100MSMD SHLDED POWER INDUCTOR |
4,046 |
|
Datasheet | CTHCCI1090F | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 10 µH | ±20% | 7 A | 5A | Shielded | 26mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.445" L x 0.409" W (11.30mm x 10.40mm) | 0.382" (9.70mm) |
|
CT8645LLF-102L-THLO CORE LOSS HI-I TOROID INDCTOR |
4,884 |
|
Datasheet | ct8645llf | - | Bulk | Active | Toroidal | - | 1 mH | ±15% | - | - | - | 284mOhm | - | - | - | -55°C ~ 125°C | - | - | Through Hole | - | - | - |
|
|
CT8645LLF-102L-TVLO CORE LOSS HI-I TOROID INDCTOR |
4,675 |
|
Datasheet | ct8645llf | - | Bulk | Active | Toroidal | - | 1 mH | ±15% | - | - | - | 284mOhm | - | - | - | -55°C ~ 125°C | - | - | Through Hole | - | - | - |
|
CT9555F-100-THHIGH CURRENT TOROID INDUCTOR |
3,543 |
|
Datasheet | ct9555f | - | Bulk | Active | Wirewound | - | 10 µH | ±15% | - | - | - | 7mOhm | - | - | - | -55°C ~ 105°C | - | - | Through Hole | - | - | - |
|
|
CT9555F-102-THHIGH CURRENT TOROID INDUCTOR |
1,493 |
|
Datasheet | ct9555f | - | Bulk | Active | Wirewound | - | 1 mH | ±15% | - | - | - | 280mOhm | - | - | - | -55°C ~ 105°C | - | - | Through Hole | - | - | - |
|
|
CT9555F-102-TVHIGH CURRENT TOROID INDUCTOR |
3,840 |
|
Datasheet | ct9555f | - | Bulk | Active | Wirewound | - | 1 mH | ±15% | - | - | - | 280mOhm | - | - | - | -55°C ~ 105°C | - | - | Through Hole | - | - | - |
|
|
CT9555F-100-TVHIGH CURRENT TOROID INDUCTOR |
1,722 |
|
Datasheet | ct9555f | - | Bulk | Active | Wirewound | - | 10 µH | ±15% | - | - | - | 7mOhm | - | - | - | -55°C ~ 105°C | - | - | Through Hole | - | - | - |
|
CTH8F-270K27UH AXIAL PWR LINE INDUCTOR |
2,361 |
|
Datasheet | CTH8F | Axial | Bulk | Active | - | - | 27 µH | ±10% | 4 A | 5.36A | Unshielded | 27mOhm Max | - | 9MHz | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Axial | 0.469" Dia x 0.921" L (11.90mm x 23.40mm) | - |
|
|
CTH8F-182K1800UH AXIAL PWR LINE INDUCTOR |
2,381 |
|
Datasheet | CTH8F | Axial | Bulk | Active | - | - | 1.8 mH | ±10% | 600 mA | 640mA | Unshielded | 1.56Ohm Max | - | 720kHz | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Axial | 0.469" Dia x 0.921" L (11.90mm x 23.40mm) | - |
|
|
CTH8F-123K12000UH AXIAL PWR LINE INDUCTOR |
3,724 |
|
Datasheet | CTH8F | Axial | Bulk | Active | - | - | 12 mH | ±10% | 160 mA | 257mA | Unshielded | 9.99Ohm Max | - | 300kHz | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Axial | 0.469" Dia x 0.921" L (11.90mm x 23.40mm) | - |
|
|
CTH8F-120K12UH AXIAL PWR LINE INDUCTOR |
3,596 |
|
Datasheet | CTH8F | Axial | Bulk | Active | - | - | 12 µH | ±10% | 4 A | 8.21A | Unshielded | 19mOhm Max | - | 17MHz | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Axial | 0.469" Dia x 0.921" L (11.90mm x 23.40mm) | - |
|
|
CTH8F-391K390UH AXIAL PWR LINE INDUCTOR |
1,808 |
|
Datasheet | CTH8F | Axial | Bulk | Active | - | - | 390 µH | ±10% | 1.6 A | 1.39A | Unshielded | 281mOhm Max | - | 2MHz | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Axial | 0.469" Dia x 0.921" L (11.90mm x 23.40mm) | - |
|
|
CTH8F-5R6K5.6UH AXIAL PWR LINE INDUCTOR |
1,254 |
|
Datasheet | CTH8F | Axial | Bulk | Active | - | - | 5.6 µH | ±10% | 4 A | 12.6A | Unshielded | 11mOhm Max | - | 29MHz | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Axial | 0.469" Dia x 0.921" L (11.90mm x 23.40mm) | - |
|
|
CTH8F-273K27000UH AXIAL PWR LINE INDUCTOR |
3,847 |
|
Datasheet | CTH8F | Axial | Bulk | Active | - | - | 27 mH | ±10% | 130 mA | 171mA | Unshielded | 18.6Ohm Max | - | 150kHz | - | -55°C ~ 125°C | 1 kHz | - | Through Hole | Axial | 0.469" Dia x 0.921" L (11.90mm x 23.40mm) | - |
Frequently Asked Questions
What are Fixed Inductors components used for?
Fixed Inductors components are used in a wide range of electronic equipment and systems. Their exact function depends on the device, circuit design and technical requirements of the application.
How do I choose the right Fixed Inductors part?
Compare the manufacturer part number, key specifications, package type, operating conditions, availability and datasheet information. For replacement projects, always verify the critical electrical and mechanical parameters before selecting an alternative.
Can JIEXIN Electronics help source obsolete or hard-to-find Fixed Inductors parts?
Yes. Send us the required manufacturer part number, quantity or BOM. Our sourcing team can help check stock availability, lead time, alternative sourcing options and quotation details.
How can I request pricing and availability?
Submit the part number, manufacturer and required quantity through our RFQ form. JIEXIN Electronics will review your request and provide available stock, pricing and sourcing information.
