Fixed Inductors
Explore Fixed Inductors parts from multiple manufacturers, with model information, availability, datasheets and technical specifications for engineering and purchasing.
For parts that are not shown in the list, send the manufacturer part number, quantity or BOM to JIEXIN Electronics. Our team can assist with availability checks and quotation support.
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CT67F-101K-VHIGH CURRENT POWER TOROID |
3,939 |
|
Datasheet | ct67f | - | Bulk | Active | Toroidal | - | 101 µH | ±10% | - | - | - | - | - | - | - | -20°C ~ 80°C | - | - | - | - | - | - |
|
CTSD10F-1R0M1UH SMD SHLDED POWER INDUCTOR |
3,584 |
|
Datasheet | CTSD10F | Nonstandard | Tape & Reel (TR) | Active | - | - | 1 µH | ±20% | - | 2.25A | Shielded | 56mOhm | - | - | - | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.205" L x 0.205" W (5.20mm x 5.20mm) | 0.039" (1.00mm) |
|
CTSCH875DF-102K1000UH RADIAL FIXED INDUCTR |
2,317 |
|
Datasheet | CTSCH875DF | Radial, Vertical Cylinder | Bulk | Active | - | - | 1 mH | ±10% | - | 230mA | Shielded | 2.72Ohm Max | - | - | - | - | 1 kHz | - | Through Hole | Radial | 0.307" Dia (7.80mm) | 0.307" (7.80mm) |
|
|
CTSCH875DF-222K2200UH RADIAL FIXED INDUCTOR |
1,472 |
|
Datasheet | CTSCH875DF | Radial, Vertical Cylinder | Bulk | Active | - | - | 2.2 mH | ±10% | - | 160mA | Shielded | 7.56Ohm Max | - | - | - | - | 1 kHz | - | Through Hole | Radial | 0.307" Dia (7.80mm) | 0.307" (7.80mm) |
|
|
CTSCH875DF-472K4700UH RADIAL FIXED INDUCTOR |
1,232 |
|
Datasheet | CTSCH875DF | Radial, Vertical Cylinder | Bulk | Active | - | - | 4.7 mH | ±10% | - | 110mA | Shielded | 14.7Ohm Max | - | - | - | - | 1 kHz | - | Through Hole | Radial | 0.307" Dia (7.80mm) | 0.307" (7.80mm) |
|
CTDO3316PF-102HC1.0UH SMD HI-CUR POWER INDUCTOR |
2,773 |
|
Datasheet | CTDO3316PF | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 1 µH | ±20% | 6.8 A | 9A | Unshielded | 10mOhm | - | 100MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.510" L x 0.370" W (12.95mm x 9.40mm) | 0.205" (5.20mm) |
|
|
CTDO3316PF-153HC15UH SMD HI-CUR POWER INDUCTOR |
2,092 |
|
Datasheet | CTDO3316PF | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 15 µH | ±20% | 3.1 A | 3A | Unshielded | 50mOhm | - | 27MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.510" L x 0.370" W (12.95mm x 9.40mm) | 0.205" (5.20mm) |
|
|
CTDO3316PF-222HC2.2UH SMD HI-CUR POWER INDUCTOR |
1,407 |
|
Datasheet | CTDO3316PF | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 2.2 µH | ±20% | 6.1 A | 7A | Unshielded | 10mOhm | - | 80MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.510" L x 0.370" W (12.95mm x 9.40mm) | 0.205" (5.20mm) |
|
|
CTDO3316PF-104HC100UH SMD HI-CUR POWER INDUCTOR |
2,410 |
|
Datasheet | CTDO3316PF | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 100 µH | ±20% | 1.3 A | 1.2A | Unshielded | 300mOhm | - | 9MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.510" L x 0.370" W (12.95mm x 9.40mm) | 0.205" (5.20mm) |
|
|
CTDO3316PF-103HC10UH SMD HI-CUR POWER INDUCTOR |
3,351 |
|
Datasheet | CTDO3316PF | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 10 µH | ±20% | 3.9 A | 3.8A | Unshielded | 40mOhm | - | 30MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.510" L x 0.370" W (12.95mm x 9.40mm) | 0.205" (5.20mm) |
|
|
CTDO3316PF-223HC22UH SMD HI-CUR POWER INDUCTOR |
4,528 |
|
Datasheet | CTDO3316PF | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 22 µH | ±20% | 2.7 A | 2.6A | Unshielded | 90mOhm | - | 19MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.510" L x 0.370" W (12.95mm x 9.40mm) | 0.205" (5.20mm) |
|
|
CTDO3316PF-331HC.33UH SMD HI-CUR POWER INDUCTOR |
3,588 |
|
Datasheet | CTDO3316HCF | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 330 nH | ±30% | 16 A | 20A | Unshielded | 2mOhm | - | - | - | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.520" L x 0.390" W (13.21mm x 9.91mm) | 0.250" (6.35mm) |
|
CTPCI7045F-4R7NSMD SHLDED POWER INDUCTOR |
1,619 |
|
Datasheet | CTPCI7045F | Nonstandard | Tape & Reel (TR) | Active | - | - | 4.7 µH | ±30% | 4.1 A | 4A | Shielded | 23.4mOhm Max | - | - | - | -40°C ~ 105°C | 100 kHz | - | Surface Mount | - | 0.291" L x 0.276" W (7.40mm x 7.00mm) | 0.189" (4.80mm) |
|
|
CTPCI7045F-6R8NSMD SHLDED POWER INDUCTOR |
2,873 |
|
Datasheet | CTPCI7045F | Nonstandard | Tape & Reel (TR) | Active | - | - | 6.8 µH | ±30% | 3.9 A | 3A | Shielded | 26.4mOhm Max | - | - | - | -40°C ~ 105°C | 100 kHz | - | Surface Mount | - | 0.291" L x 0.276" W (7.40mm x 7.00mm) | 0.189" (4.80mm) |
|
|
CTPCI7045F-100MSMD SHLDED POWER INDUCTOR |
4,512 |
|
Datasheet | CTPCI7045F | Nonstandard | Tape & Reel (TR) | Active | - | - | 10 µH | ±20% | 3.1 A | 2.6A | Shielded | 39.6mOhm Max | - | - | - | -40°C ~ 105°C | 100 kHz | - | Surface Mount | - | 0.291" L x 0.276" W (7.40mm x 7.00mm) | 0.189" (4.80mm) |
|
|
CTPCI7045F-471MSMD SHLDED POWER INDUCTOR |
4,939 |
|
Datasheet | CTPCI7045F | Nonstandard | Tape & Reel (TR) | Active | - | - | 470 µH | ±20% | 460 mA | 370mA | Shielded | 1.44Ohm Max | - | - | - | -40°C ~ 105°C | 100 kHz | - | Surface Mount | - | 0.291" L x 0.276" W (7.40mm x 7.00mm) | 0.189" (4.80mm) |
|
|
CTPCI7045F-221MSMD SHLDED POWER INDUCTOR |
2,162 |
|
Datasheet | CTPCI7045F | Nonstandard | Tape & Reel (TR) | Active | - | - | 220 µH | ±20% | 750 mA | 540mA | Shielded | 660mOhm Max | - | - | - | -40°C ~ 105°C | 100 kHz | - | Surface Mount | - | 0.291" L x 0.276" W (7.40mm x 7.00mm) | 0.189" (4.80mm) |
|
|
CTPCI7045F-1R0NSMD SHLDED POWER INDUCTOR |
2,990 |
|
Datasheet | CTPCI7045F | Nonstandard | Tape & Reel (TR) | Active | - | - | 1 µH | ±30% | 6.5 A | 7.6A | Shielded | 11.7mOhm Max | - | - | - | -40°C ~ 105°C | 100 kHz | - | Surface Mount | - | 0.291" L x 0.276" W (7.40mm x 7.00mm) | 0.189" (4.80mm) |
|
|
CTPCI7045F-470MSMD SHLDED POWER INDUCTOR |
3,468 |
|
Datasheet | CTPCI7045F | Nonstandard | Tape & Reel (TR) | Active | - | - | 47 µH | ±20% | 1.7 A | 1.1A | Shielded | 156mOhm Max | - | - | - | -40°C ~ 105°C | 100 kHz | - | Surface Mount | - | 0.291" L x 0.276" W (7.40mm x 7.00mm) | 0.189" (4.80mm) |
|
|
CTPCI7045F-220MSMD SHLDED POWER INDUCTOR |
3,369 |
|
Datasheet | CTPCI7045F | Nonstandard | Tape & Reel (TR) | Active | - | - | 22 µH | ±20% | 2.2 A | 1.6A | Shielded | 82.8mOhm Max | - | - | - | -40°C ~ 105°C | 100 kHz | - | Surface Mount | - | 0.291" L x 0.276" W (7.40mm x 7.00mm) | 0.189" (4.80mm) |
Frequently Asked Questions
What are Fixed Inductors components used for?
Fixed Inductors components are used in a wide range of electronic equipment and systems. Their exact function depends on the device, circuit design and technical requirements of the application.
How do I choose the right Fixed Inductors part?
Compare the manufacturer part number, key specifications, package type, operating conditions, availability and datasheet information. For replacement projects, always verify the critical electrical and mechanical parameters before selecting an alternative.
Can JIEXIN Electronics help source obsolete or hard-to-find Fixed Inductors parts?
Yes. Send us the required manufacturer part number, quantity or BOM. Our sourcing team can help check stock availability, lead time, alternative sourcing options and quotation details.
How can I request pricing and availability?
Submit the part number, manufacturer and required quantity through our RFQ form. JIEXIN Electronics will review your request and provide available stock, pricing and sourcing information.
