Fixed Inductors
Explore Fixed Inductors parts from multiple manufacturers, with model information, availability, datasheets and technical specifications for engineering and purchasing.
For parts that are not shown in the list, send the manufacturer part number, quantity or BOM to JIEXIN Electronics. Our team can assist with availability checks and quotation support.
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
4922-561LFIXED IND 560NH 5.8A 10.5MOHM SM |
3,650 |
|
Datasheet | 4922 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 560 nH | ±15% | 5.8 A | 5.8A | Unshielded | 10.5mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Surface Mount | - | 0.505" L x 0.240" W (12.82mm x 6.09mm) | 0.230" (5.84mm) |
|
|
4922-821LFIXED IND 820NH 5.6A 12 MOHM SMD |
4,128 |
|
Datasheet | 4922 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 820 nH | ±15% | 5.6 A | 5.6A | Unshielded | 12mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Surface Mount | - | 0.505" L x 0.240" W (12.82mm x 6.09mm) | 0.230" (5.84mm) |
|
|
4922R-221LFIXED IND 220NH 7A 8 MOHM SMD |
4,691 |
|
Datasheet | 4922R | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 220 nH | ±15% | 7 A | 7A | Unshielded | 8mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Surface Mount | - | 0.505" L x 0.240" W (12.82mm x 6.09mm) | 0.230" (5.84mm) |
|
|
4922R-27LFIXED IND 150UH 630MA 998MOHM SM |
2,070 |
|
Datasheet | 4922R | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 150 µH | ±15% | 630 mA | 630mA | Unshielded | 998mOhm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Surface Mount | - | 0.505" L x 0.240" W (12.82mm x 6.09mm) | 0.230" (5.84mm) |
|
|
4922R-28LFIXED IND 180UH 530MA 1.37OHM SM |
3,277 |
|
Datasheet | 4922R | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 180 µH | ±15% | 530 mA | 530mA | Unshielded | 1.37Ohm Max | - | - | - | -55°C ~ 125°C | 1 kHz | - | Surface Mount | - | 0.505" L x 0.240" W (12.82mm x 6.09mm) | 0.230" (5.84mm) |
|
HCM1A1707V2-1R5-RFIXED IND 1.5UH 23A 2.24MOHM SMD |
1,175 |
|
Datasheet | HCM1AV2 | Nonstandard | Tape & Reel (TR) | Active | - | Iron Powder | 1.5 µH | ±20% | 23 A | 41A | Shielded | 2.24mOhm Max | - | 25MHz | AEC-Q200 | -55°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.675" L x 0.675" W (17.15mm x 17.15mm) | 0.276" (7.00mm) |
|
|
HCM1A1707V2-3R3-RFIXED IND 3.3UH 19.5A 3.27 MOHM |
3,047 |
|
Datasheet | HCM1AV2 | Nonstandard | Tape & Reel (TR) | Active | - | Iron Powder | 3.3 µH | ±20% | 19.5 A | 28A | Shielded | 3.27mOhm Max | - | 15MHz | AEC-Q200 | -55°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.675" L x 0.675" W (17.15mm x 17.15mm) | 0.276" (7.00mm) |
|
|
HCM1A1707V2-1R0-RFIXED IND 1UH 36A 1.46 MOHM SMD |
2,709 |
|
Datasheet | HCM1AV2 | Nonstandard | Tape & Reel (TR) | Active | - | Iron Powder | 1 µH | ±20% | 36 A | 57A | Shielded | 1.46mOhm Max | - | 34MHz | AEC-Q200 | -55°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.675" L x 0.675" W (17.15mm x 17.15mm) | 0.276" (7.00mm) |
|
|
HCM1A1707V2-6R8-RFIXED IND 6.8UH 14A 7.16MOHM SMD |
3,406 |
|
Datasheet | HCM1AV2 | Nonstandard | Tape & Reel (TR) | Active | - | Iron Powder | 6.8 µH | ±20% | 14 A | 20A | Shielded | 7.16mOhm Max | - | 9MHz | AEC-Q200 | -55°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.675" L x 0.675" W (17.15mm x 17.15mm) | 0.276" (7.00mm) |
|
1840-00JFIXED IND 150NH 3.05A 30 MOHM TH |
3,903 |
|
Datasheet | 1840 | Axial | Tape & Reel (TR) | Active | Molded | Phenolic | 150 nH | ±5% | 3.05 A | - | Unshielded | 30mOhm Max | 55 @ 25MHz | 510MHz | - | -55°C ~ 125°C | 25 MHz | - | Through Hole | - | 0.187" Dia x 0.437" L (4.75mm x 11.10mm) | - |
|
|
1840-02JFIXED IND 220NH 2.82A 35 MOHM TH |
4,298 |
|
Datasheet | 1840 | Axial | Tape & Reel (TR) | Active | Molded | Phenolic | 220 nH | ±5% | 2.82 A | - | Unshielded | 35mOhm Max | 55 @ 25MHz | 415MHz | - | -55°C ~ 125°C | 25 MHz | - | Through Hole | - | 0.187" Dia x 0.437" L (4.75mm x 11.10mm) | - |
|
|
1840-04JFIXED IND 330NH 2.36A 50 MOHM TH |
4,780 |
|
Datasheet | 1840 | Axial | Tape & Reel (TR) | Active | Molded | Phenolic | 330 nH | ±5% | 2.36 A | - | Unshielded | 50mOhm Max | 55 @ 25MHz | 350MHz | - | -55°C ~ 125°C | 25 MHz | - | Through Hole | - | 0.187" Dia x 0.437" L (4.75mm x 11.10mm) | - |
|
|
1840-05JFIXED IND 390NH 1.86A 80 MOHM TH |
2,009 |
|
Datasheet | 1840 | Axial | Tape & Reel (TR) | Active | Molded | Phenolic | 390 nH | ±5% | 1.86 A | - | Unshielded | 80mOhm Max | 55 @ 25MHz | 300MHz | - | -55°C ~ 125°C | 25 MHz | - | Through Hole | - | 0.187" Dia x 0.437" L (4.75mm x 11.10mm) | - |
|
|
1840-06JFIXED IND 470NH 1.86A 80 MOHM TH |
2,703 |
|
Datasheet | 1840 | Axial | Tape & Reel (TR) | Active | Molded | Phenolic | 470 nH | ±5% | 1.86 A | - | Unshielded | 80mOhm Max | 55 @ 25MHz | 300MHz | - | -55°C ~ 125°C | 25 MHz | - | Through Hole | - | 0.187" Dia x 0.437" L (4.75mm x 11.10mm) | - |
|
|
PL8600NLTFIXED IND 2.2UH 8.3A 8 MOHM SMD |
2,491 |
|
Datasheet | - | Nonstandard | Tape & Reel (TR) | Active | Toroidal | - | 2.2 µH | ±10% | 8.3 A | - | Unshielded | 8mOhm Max | - | - | - | -40°C ~ 130°C | - | - | Surface Mount | - | 0.625" L x 0.525" W (15.88mm x 13.34mm) | 0.320" (8.12mm) |
|
|
PL8603NLTFIXED IND 10.4UH 3.8A 30MOHM SMD |
3,346 |
|
Datasheet | - | Nonstandard | Tape & Reel (TR) | Active | Toroidal | - | 10.4 µH | ±10% | 3.8 A | - | Unshielded | 30mOhm Max | - | - | - | -40°C ~ 130°C | - | - | Surface Mount | - | 0.625" L x 0.525" W (15.88mm x 13.34mm) | 0.320" (8.12mm) |
|
PL8603TFIXED IND 10.4UH 3.8A 30MOHM SMD |
4,256 |
|
Datasheet | - | Nonstandard | Tape & Reel (TR) | Active | Toroidal | - | 10.4 µH | ±10% | 3.8 A | - | Unshielded | 30mOhm Max | - | - | - | -40°C ~ 130°C | - | - | Surface Mount | - | 0.625" L x 0.525" W (15.88mm x 13.34mm) | 0.320" (8.12mm) |
|
ATCA-08-681M-HFIXED IND 680UH 5A 105 MOHM TH |
2,241 |
|
Datasheet | ATCA | Radial, Horizontal (Open) | Tray | Active | Toroidal | Iron Powder | 680 µH | ±20% | 5 A | - | Unshielded | 105mOhm Max | - | - | - | -40°C ~ 105°C | 1 kHz | - | Through Hole | - | 1.673" Dia (42.50mm) | 0.846" (21.50mm) |
|
|
1945R-01GFIXED IND 2.7UH 1.6A 110 MOHM TH |
1,441 |
|
Datasheet | 1945R | Axial | Tape & Reel (TR) | Active | Molded | Iron | 2.7 µH | ±2% | 1.6 A | - | Unshielded | 110mOhm | 55 @ 10MHz | 88MHz | - | -55°C ~ 125°C | 7.9 MHz | - | Through Hole | - | 0.193" Dia x 0.447" L (4.90mm x 11.35mm) | - |
|
|
1945R-02GFIXED IND 3.3UH 1.4A 140 MOHM TH |
3,479 |
|
Datasheet | 1945R | Axial | Tape & Reel (TR) | Active | Molded | Iron | 3.3 µH | ±2% | 1.4 A | - | Unshielded | 140mOhm | 55 @ 10MHz | 80MHz | - | -55°C ~ 125°C | 7.9 MHz | - | Through Hole | - | 0.193" Dia x 0.447" L (4.90mm x 11.35mm) | - |
Frequently Asked Questions
What are Fixed Inductors components used for?
Fixed Inductors components are used in a wide range of electronic equipment and systems. Their exact function depends on the device, circuit design and technical requirements of the application.
How do I choose the right Fixed Inductors part?
Compare the manufacturer part number, key specifications, package type, operating conditions, availability and datasheet information. For replacement projects, always verify the critical electrical and mechanical parameters before selecting an alternative.
Can JIEXIN Electronics help source obsolete or hard-to-find Fixed Inductors parts?
Yes. Send us the required manufacturer part number, quantity or BOM. Our sourcing team can help check stock availability, lead time, alternative sourcing options and quotation details.
How can I request pricing and availability?
Submit the part number, manufacturer and required quantity through our RFQ form. JIEXIN Electronics will review your request and provide available stock, pricing and sourcing information.
