Fixed Inductors
Review Fixed Inductors Inductors, Coils, Chokes components in this filtered selection. Compare manufacturer information, availability, pricing, datasheets and key specifications to narrow down suitable parts for your application.
If the exact part or specification you need is not listed, send the manufacturer part number, target parameters and quantity to JIEXIN Electronics for sourcing and quotation support.
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CSCF2915H-2R2MCSMD HIGH CURRENT POWER INDUCTOR |
160 |
|
Datasheet | CSCF2915H | Nonstandard | Tray | Active | Wirewound | Ferrite | 2.2 µH | ±20% | 32 A | 100A | Shielded | 1.65mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | Mn-Zn Ferrite Low Loss | Surface Mount | - | 1.098" L x 0.776" W (27.90mm x 19.70mm) | 0.606" (15.40mm) |
|
|
CSCF2915L-6R8MCSMD HIGH CURRENT POWER INDUCTOR |
160 |
|
Datasheet | CSCF2915L | Nonstandard | Tray | Active | Wirewound | Ferrite | 6.8 µH | ±20% | 34 A | 27.8A | Shielded | 1.36mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | Mn-Zn Ferrite Low Loss | Surface Mount | 3-SMD | 1.098" L x 0.776" W (27.90mm x 19.70mm) | 0.606" (15.40mm) |
|
|
CSCF2918H-220MCSMD HIGH CURRENT POWER INDUCTOR |
134 |
|
Datasheet | CSCF2918H | Nonstandard | Tray | Active | Wirewound | Ferrite | 22 µH | ±20% | 30 A | 15A | Shielded | 2.58mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | Mn-Zn Ferrite Low Loss | Surface Mount | - | 1.102" L x 0.776" W (28.00mm x 19.70mm) | 0.728" (18.50mm) |
|
|
CSCF2918H-6R8MCSMD HIGH CURRENT POWER INDUCTOR |
113 |
|
Datasheet | CSCF2918H | Nonstandard | Tray | Active | Wirewound | Ferrite | 6.8 µH | ±20% | 30 A | 48A | Shielded | 2.58mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | Mn-Zn Ferrite Low Loss | Surface Mount | - | 1.102" L x 0.776" W (28.00mm x 19.70mm) | 0.728" (18.50mm) |
|
CSCF2918H-100MCSMD HIGH CURRENT POWER INDUCTOR |
378 |
|
Datasheet | CSCF2918H | Nonstandard | Tray | Active | Wirewound | Ferrite | 10 µH | ±20% | 30 A | 33A | Shielded | 2.58mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | Mn-Zn Ferrite Low Loss | Surface Mount | - | 1.102" L x 1.063" W (28.00mm x 27.00mm) | 0.728" (18.50mm) |
|
CPD2315-100MCLASS D INDUCTOR FOR DIGITAL AMP |
371 |
|
Datasheet | CPD2315 | Nonstandard | Tray | Active | Wirewound | Ferrite | 10 µH | ±20% | 14 A | 39A | Shielded | 7.8mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | Low Loss, Soft Saturation | Through Hole | Vertical, 3 PC Pin | 0.906" L x 0.571" W (23.00mm x 14.50mm) | 0.906" (23.00mm) |
|
CPD1521C-220MCLASS D INDUCTOR FOR DIGITAL AMP |
231 |
|
Datasheet | CPD1521C | Nonstandard | Tray | Active | Wirewound | Ferrite | 22 µH | ±20% | 8 A | 10A | Shielded | 16mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | Low Loss, Soft Saturation | Through Hole | Radial - 4 Leads | 0.846" L x 0.591" W (21.50mm x 15.00mm) | 0.618" (15.70mm) |
|
|
CPD1521C-100MCLASS D INDUCTOR FOR DIGITAL AMP |
144 |
|
Datasheet | CPD1521C | Nonstandard | Tray | Active | Wirewound | Ferrite | 10 µH | ±20% | 11 A | 15A | Shielded | 8.4mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | Low Loss, Soft Saturation | Through Hole | Radial - 4 Leads | 0.846" L x 0.591" W (21.50mm x 15.00mm) | 0.618" (15.70mm) |
|
CSBL2212-150MSMD HIGH CURRENT POWER INDUCTOR |
108 |
|
Datasheet | CSBL2212 | Nonstandard | Cut Tape (CT) | Active | Wirewound | Metal Composite | 15 µH | ±20% | 18 A | 26A | Shielded | 5.45mOhm Max | - | - | AEC-Q200 | -50°C ~ 150°C | 100 kHz | Flat Wire, High Q Value | Surface Mount | - | 0.886" L x 0.866" W (22.50mm x 22.00mm) | 0.488" (12.40mm) |
|
|
CSBL2212-3R3MSMD HIGH CURRENT POWER INDUCTOR |
103 |
|
Datasheet | CSBL2212 | Nonstandard | Cut Tape (CT) | Active | Wirewound | Metal Composite | 3.3 µH | ±20% | 32 A | 50A | Shielded | 1.2mOhm Max | - | - | AEC-Q200 | -50°C ~ 150°C | 100 kHz | Flat Wire, High Q Value | Surface Mount | - | 0.886" L x 0.866" W (22.50mm x 22.00mm) | 0.488" (12.40mm) |
Frequently Asked Questions
What are Fixed Inductors components used for?
Fixed Inductors components are used in a wide range of electronic equipment and systems. Their exact function depends on the device, circuit design and technical requirements of the application.
How do I choose the right Fixed Inductors part?
Compare the manufacturer part number, key specifications, package type, operating conditions, availability and datasheet information. For replacement projects, always verify the critical electrical and mechanical parameters before selecting an alternative.
Can JIEXIN Electronics help source obsolete or hard-to-find Fixed Inductors parts?
Yes. Send us the required manufacturer part number, quantity or BOM. Our sourcing team can help check stock availability, lead time, alternative sourcing options and quotation details.
How can I request pricing and availability?
Submit the part number, manufacturer and required quantity through our RFQ form. JIEXIN Electronics will review your request and provide available stock, pricing and sourcing information.
