Fixed Inductors
Explore Fixed Inductors parts from multiple manufacturers, with model information, availability, datasheets and technical specifications for engineering and purchasing.
For parts that are not shown in the list, send the manufacturer part number, quantity or BOM to JIEXIN Electronics. Our team can assist with availability checks and quotation support.
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
RCH108NP-8R2MFIXED IND 8.2UH 5A 17 MOHM TH |
1,962 |
|
Datasheet | RCH-108 | Radial, Vertical Cylinder, 4 Leads (Open) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 8.2 µH | ±20% | 5 A | - | Unshielded | 17mOhm Max | - | - | - | -40°C ~ 100°C | 7.96 MHz | - | Through Hole | - | 0.394" Dia (10.00mm) | 0.335" (8.50mm) |
|
SDR2207-R80MFIXED IND 800NH 16A 2.8 MOHM SMD |
1,024 |
|
Datasheet | SDR2207 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 800 nH | ±20% | 16 A | 35A | Unshielded | 2.8mOhm Max | 30 @ 5MHz | 102MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.866" L x 0.591" W (22.00mm x 15.00mm) | 0.307" (7.80mm) |
|
|
SDR2207-4R7MFIXED IND 4.7UH 8.5A 8.8MOHM SMD |
2,233 |
|
Datasheet | SDR2207 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 4.7 µH | ±20% | 8.5 A | 15A | Unshielded | 8.8mOhm Max | 38 @ 3MHz | 33MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.866" L x 0.591" W (22.00mm x 15.00mm) | 0.307" (7.80mm) |
|
|
SDR2207-100MFIXED IND 10UH 6.5A 17.2MOHM SMD |
3,096 |
|
Datasheet | SDR2207 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 10 µH | ±20% | 6.5 A | 10A | Unshielded | 17.2mOhm Max | 53 @ 5MHz | 20MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.866" L x 0.591" W (22.00mm x 15.00mm) | 0.307" (7.80mm) |
|
|
SDR2207-220YFIXED IND 22UH 4A 39.4 MOHM SMD |
3,778 |
|
Datasheet | SDR2207 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 22 µH | ±15% | 4 A | 6.5A | Unshielded | 39.4mOhm Max | 27 @ 3MHz | 14MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.866" L x 0.591" W (22.00mm x 15.00mm) | 0.307" (7.80mm) |
|
|
SDR2207-330KFIXED IND 33UH 3.4A 58.4MOHM SMD |
4,605 |
|
Datasheet | SDR2207 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 33 µH | ±10% | 3.4 A | 5.5A | Unshielded | 58.4mOhm Max | 27 @ 3MHz | 11MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.866" L x 0.591" W (22.00mm x 15.00mm) | 0.307" (7.80mm) |
|
|
SDR2207-101KFIXED IND 100UH 2.2A 168MOHM SMD |
2,691 |
|
Datasheet | SDR2207 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 100 µH | ±10% | 2.2 A | 3A | Unshielded | 168mOhm Max | 18 @ 2MHz | 6.2MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.866" L x 0.591" W (22.00mm x 15.00mm) | 0.307" (7.80mm) |
|
|
SRP1038CC-270MIND SMD 27UH 4.5A |
2,642 |
|
Datasheet | SRP1038CC | Nonstandard | Tape & Reel (TR) | Active | Wirewound | Carbonyl Powder | 27 µH | ±20% | 4.5 A | 6.5A | Shielded | 96mOhm Max | - | 7MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.433" L x 0.394" W (11.00mm x 10.00mm) | 0.157" (4.00mm) |
|
SRP7030-220MFIXED IND 22UH SMD |
4,136 |
|
Datasheet | SRP7030 | Nonstandard | Tape & Reel (TR) | Active | - | Iron | 22 µH | ±20% | - | - | Shielded | - | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.307" L x 0.276" W (7.80mm x 7.00mm) | 0.126" (3.20mm) |
|
|
ASPI-5050LR-8R2M-TIND 8.2UH 6.1A 32.5M |
3,753 |
|
Datasheet | ASPI-5050LR | Nonstandard | Tape & Reel (TR) | Active | Molded | Alloy Powder | 8.2 µH | ±20% | 6.1 A | 6.1A | Shielded | 32.5mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.236" L x 0.224" W (6.00mm x 5.70mm) | 0.197" (5.00mm) |
|
|
ASPI-5050LR-150M-TIND 15UH 4A 66.0M |
1,360 |
|
Datasheet | ASPI-5050LR | Nonstandard | Tape & Reel (TR) | Active | Molded | Alloy Powder | 15 µH | ±20% | 4 A | 4.6A | Shielded | 66mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.236" L x 0.224" W (6.00mm x 5.70mm) | 0.197" (5.00mm) |
|
|
ASPI-5050LR-5R6M-TIND 5.6UH 7.2A 24.2M |
2,541 |
|
Datasheet | ASPI-5050LR | Nonstandard | Tape & Reel (TR) | Active | Molded | Alloy Powder | 5.6 µH | ±20% | 7.2 A | 7.2A | Shielded | 24.2mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.236" L x 0.224" W (6.00mm x 5.70mm) | 0.197" (5.00mm) |
|
|
ASPI-5050LR-6R8M-TIND 6.8UH 6.4A 28.6M |
3,624 |
|
Datasheet | ASPI-5050LR | Nonstandard | Tape & Reel (TR) | Active | Molded | Alloy Powder | 6.8 µH | ±20% | 6.4 A | 6.6A | Shielded | 28.6mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.236" L x 0.224" W (6.00mm x 5.70mm) | 0.197" (5.00mm) |
|
ASPI-5050LR-220M-TIND 22UH 3.4A 99.7M |
1,499 |
|
Datasheet | ASPI-5050LR | Nonstandard | Tape & Reel (TR) | Active | Molded | Alloy Powder | 22 µH | ±20% | 3.4 A | 4.1A | Shielded | 99.7mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.236" L x 0.224" W (6.00mm x 5.70mm) | 0.197" (5.00mm) |
|
|
CDRR94ANP-100MCFIXED IND 10UH 2.5A 51.2MOHM SMD |
3,622 |
|
Datasheet | CDRR94A | Nonstandard | Tape & Reel (TR) | Obsolete | - | Ferrite | 10 µH | ±20% | 2.5 A | 2.48A | Shielded | 51.2mOhm Max | - | - | - | -40°C ~ 100°C | 100 kHz | - | Surface Mount | - | 0.508" L x 0.370" W (12.90mm x 9.40mm) | 0.197" (5.00mm) |
|
|
CDRR94ANP-121MCFIXED IND 120UH 640MA 526.8 MOHM |
4,614 |
|
Datasheet | CDRR94A | Nonstandard | Tape & Reel (TR) | Obsolete | - | Ferrite | 120 µH | ±20% | 640 mA | 710mA | Shielded | 526.8mOhm Max | - | - | - | -40°C ~ 100°C | 100 kHz | - | Surface Mount | - | 0.508" L x 0.370" W (12.90mm x 9.40mm) | 0.197" (5.00mm) |
|
|
CDRR94ANP-181MCFIXED IND 180UH 540MA 784.8 MOHM |
3,204 |
|
Datasheet | CDRR94A | Nonstandard | Tape & Reel (TR) | Obsolete | - | Ferrite | 180 µH | ±20% | 540 mA | 600mA | Shielded | 784.8mOhm Max | - | - | - | -40°C ~ 100°C | 100 kHz | - | Surface Mount | - | 0.508" L x 0.370" W (12.90mm x 9.40mm) | 0.197" (5.00mm) |
|
|
CDRR94ANP-1R5MCFIXED IND 1.5UH 4.8A 17 MOHM SMD |
1,177 |
|
Datasheet | CDRR94A | Nonstandard | Tape & Reel (TR) | Obsolete | - | Ferrite | 1.5 µH | ±20% | 4.8 A | 6.24A | Shielded | 17mOhm Max | - | - | - | -40°C ~ 100°C | 100 kHz | - | Surface Mount | - | 0.508" L x 0.370" W (12.90mm x 9.40mm) | 0.197" (5.00mm) |
|
|
CDRR94ANP-220MCFIXED IND 22UH 1.72A 95.6MOHM SM |
3,275 |
|
Datasheet | CDRR94A | Nonstandard | Tape & Reel (TR) | Obsolete | - | Ferrite | 22 µH | ±20% | 1.72 A | 1.66A | Shielded | 95.6mOhm Max | - | - | - | -40°C ~ 100°C | 100 kHz | - | Surface Mount | - | 0.508" L x 0.370" W (12.90mm x 9.40mm) | 0.197" (5.00mm) |
|
|
CDRR94ANP-270MCFIXED IND 27UH 1.6A 112 MOHM SMD |
3,843 |
|
Datasheet | CDRR94A | Nonstandard | Tape & Reel (TR) | Obsolete | - | Ferrite | 27 µH | ±20% | 1.6 A | 1.56A | Shielded | 112mOhm Max | - | - | - | -40°C ~ 100°C | 100 kHz | - | Surface Mount | - | 0.508" L x 0.370" W (12.90mm x 9.40mm) | 0.197" (5.00mm) |
Frequently Asked Questions
What are Fixed Inductors components used for?
Fixed Inductors components are used in a wide range of electronic equipment and systems. Their exact function depends on the device, circuit design and technical requirements of the application.
How do I choose the right Fixed Inductors part?
Compare the manufacturer part number, key specifications, package type, operating conditions, availability and datasheet information. For replacement projects, always verify the critical electrical and mechanical parameters before selecting an alternative.
Can JIEXIN Electronics help source obsolete or hard-to-find Fixed Inductors parts?
Yes. Send us the required manufacturer part number, quantity or BOM. Our sourcing team can help check stock availability, lead time, alternative sourcing options and quotation details.
How can I request pricing and availability?
Submit the part number, manufacturer and required quantity through our RFQ form. JIEXIN Electronics will review your request and provide available stock, pricing and sourcing information.
