Fixed Inductors
Review Fixed Inductors Inductors, Coils, Chokes components in this filtered selection. Compare manufacturer information, availability, pricing, datasheets and key specifications to narrow down suitable parts for your application.
If the exact part or specification you need is not listed, send the manufacturer part number, target parameters and quantity to JIEXIN Electronics for sourcing and quotation support.
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SRP1238A-R60MFIXED IND 600NH 29A 2.2 MOHM SMD |
1,105 |
|
Datasheet | SRP1238A | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Carbonyl Powder | 600 nH | ±20% | 29 A | 51A | Shielded | 2.2mOhm Max | 15 @ 100kHz | 53MHz | AEC-Q200 | -40°C ~ 150°C | 100 kHz | - | Surface Mount | - | 0.531" L x 0.492" W (13.50mm x 12.50mm) | 0.138" (3.50mm) |
|
SRP5030TA-R33MFIXED IND 330NH 14A 5 MOHM SMD |
3,768 |
|
Datasheet | SRP5030TA | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Carbonyl Powder | 330 nH | ±20% | 14 A | 18A | Shielded | 5mOhm Max | 5 @ 100kHz | 110MHz | AEC-Q200 | -40°C ~ 150°C | 100 kHz | - | Surface Mount | - | 0.224" L x 0.205" W (5.70mm x 5.20mm) | 0.118" (3.00mm) |
|
9230-84-RCFIXED IND 470UH 50MA 42 OHM TH |
3,339 |
|
Datasheet | 9230 | Axial | Bulk | Active | Molded | Ferrite | 470 µH | ±10% | 50 mA | - | Unshielded | 42Ohm Max | 30 @ 790kHz | 6MHz | - | -55°C ~ 125°C | 790 kHz | - | Through Hole | - | 0.095" Dia x 0.250" L (2.41mm x 6.35mm) | - |
|
SDR2207-102KLFIXED IND 1MH 600MA 1.8 OHM SMD |
3,258 |
|
Datasheet | SDR2207 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 1 mH | ±10% | 600 mA | 1A | Unshielded | 1.8Ohm Max | 15 @ 1MHz | 3.5MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.866" L x 0.591" W (22.00mm x 15.00mm) | 0.307" (7.80mm) |
|
SRP5030CA-R16MFIXED IND 160NH 22.2A 2.33 MOHM |
1,273 |
|
Datasheet | SRP5030CA | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Iron Powder | 160 nH | ±20% | 22.2 A | 35A | Shielded | 2.33mOhm Max | - | 140MHz | AEC-Q200 | -55°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.217" L x 0.209" W (5.50mm x 5.30mm) | 0.122" (3.10mm) |
|
SRP1265A-R36MFIXED IND 360NH 45A 0.9 MOHM SMD |
2,213 |
|
Datasheet | SRP1265A | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Carbonyl Powder | 360 nH | ±20% | 45 A | 66A | Shielded | 0.9mOhm Max | 10 @ 100kHz | 80MHz | AEC-Q200 | -55°C ~ 150°C | 100 kHz | - | Surface Mount | - | 0.531" L x 0.492" W (13.50mm x 12.50mm) | 0.252" (6.40mm) |
|
SRP1245A-R68MFIXED IND 680NH 34A 1.7 MOHM SMD |
1,762 |
|
Datasheet | SRP1245A | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Carbonyl Powder | 680 nH | ±20% | 34 A | 54A | Shielded | 1.7mOhm Max | 20 @ 100kHz | 50MHz | AEC-Q200 | -40°C ~ 150°C | 100 kHz | - | Surface Mount | - | 0.531" L x 0.492" W (13.50mm x 12.50mm) | 0.197" (5.00mm) |
|
SRP7030CA-8R2MFIXED IND 8.2UH 5.9A 0.04873OHM |
4,854 |
|
Datasheet | SRP7030CA | Nonstandard | Tape & Reel (TR) | Active | - | Carbonyl Powder | 8.2 µH | ±20% | 5.9 A | 10.2A | Shielded | 48.73mOhm Max | - | 12MHz | AEC-Q200 | -55°C ~ 155°C | 100 kHz | Flat Wire, High Saturation | Surface Mount | - | 0.307" L x 0.299" W (7.80mm x 7.60mm) | 0.122" (3.10mm) |
|
9250A-152-RCFIXED IND 1.5UH 815MA 120MOHM TH |
1,554 |
|
Datasheet | 9250A | Axial | Bulk | Active | Molded | Ferrite | 1.5 µH | ±10% | 815 mA | 815mA | Shielded | 120mOhm Max | 44 @ 7.9MHz | 115MHz | - | -55°C ~ 125°C | 7.9 MHz | - | Through Hole | - | 0.162" Dia x 0.410" L (4.11mm x 10.41mm) | - |
|
9250A-331-RCFIXED IND 330NH 780MA 130MOHM TH |
2,285 |
|
Datasheet | 9250A | Axial | Bulk | Active | Molded | Ferrite | 330 nH | ±10% | 780 mA | 780mA | Shielded | 130mOhm Max | 46 @ 25MHz | 250MHz | - | -55°C ~ 125°C | 25 MHz | - | Through Hole | - | 0.162" Dia x 0.410" L (4.11mm x 10.41mm) | - |
Frequently Asked Questions
What are Fixed Inductors components used for?
Fixed Inductors components are used in a wide range of electronic equipment and systems. Their exact function depends on the device, circuit design and technical requirements of the application.
How do I choose the right Fixed Inductors part?
Compare the manufacturer part number, key specifications, package type, operating conditions, availability and datasheet information. For replacement projects, always verify the critical electrical and mechanical parameters before selecting an alternative.
Can JIEXIN Electronics help source obsolete or hard-to-find Fixed Inductors parts?
Yes. Send us the required manufacturer part number, quantity or BOM. Our sourcing team can help check stock availability, lead time, alternative sourcing options and quotation details.
How can I request pricing and availability?
Submit the part number, manufacturer and required quantity through our RFQ form. JIEXIN Electronics will review your request and provide available stock, pricing and sourcing information.
